Chenbro RM14604-0100C0 1U 4-bay ATX (12"x9.6") Tool-less Compact Server Chassis

MPN: RM14604-0100C0

Main Features

• MB Form Factor: ATX (12" x 9.6")
• Drive Bays
• -3.5" Hot-swap: 4
• -Internal 2.5": 2
• -Slim ODD: 1
• Storage Backplane: 1 x 4-port 12Gbps SATA & SAS Backplane
• PSU Form Factor: PSU, 350W, 1+1 Redundant, 80+ Gold
• Indicator
• -1 x Power Status
• -2 x LAN Activity
• -1 x HDD Activity
• -1 x Status
• -1 x UID
• Front Control
• -1 x Power On/Off
• -1 x System Reset
• -1 x UID
• -2 x USB 3.0
• Cooling Fan: 3 x Fan, 40mm, T28, PWM, Ball Bearing, L500mm
• System Security: N/A
• Dimension (D x W x H)
• -550 x 438.5 x 43.2 (mm)
• -21.6" x 17.2" x 1.7"
• Net Weight: 7.5kg
• Gross Weight: 10.0kg
• Includes
• -4 x 3.5" HDD Tray, Tool-less, Black/Blue
• -1 x 4-port 12Gbps SATA & SAS Backplane
• -3 x Fan, 40mm, T28, PWM, Ball Bearing, L500mm
• -5 x Fan Dummy Cover, Black, for Air Flow Management
• -1 x LED Board
• -1 x Display LED& Switch Cable (Discrete Pin), 900mm
• -2 x 2.5" HDD Holder, Internal, Tool-less, Blue
• -1 x USB 3.0 Cable, 2-port, 20P to Type A, 750mm
• -1 x Top Cover, Rear, Tool-less
• -1 x Top Cover, Front, Screw
• -1 x PCI Dummy Cover, for Slot Opening
• -1 x Cabinet Mounting Handle Set (2pcs/set), Left and Right, Black/Blue
• PSU, 350W, 1+1 Redundant, 80+ Gold
• 1 x Single Packing Carton, w/ Chenbro Logo
• *All images and descriptions are for illustrative purposes only. Visual representation of the products may not be perfectly accurate. Product specification, functions and appearance may vary by models and differ from country to country. All specifications are subject to change without notice. Although we endeavor to present the most precise and comprehensive information at the time of publication, a small number of items may contain typography or photography errors. Products may not be available in all markets. We recommend you to check with sales for exact offers.

Shipping Notes:

Our ChenBro products are shipping from any of the following locations:

• Monrovia, CA 91016 (Most usual)
• San Jose, CA 95132
• Hanover Park, IL 60133
• Miami, FL 33122
• Edison, NJ 08837

International orders may take an additional 2 to 3 days.
