ASRock 1U2S-B650 Server - 1U Ryzen7000 S1718 2x2.5SATA 1x3.5SATA 315W Retail

Marketing Information

1U2S-B650

• 1U Rackmount with 1, 80-PLUS Gold, 315W PSU
• Single Socket AM5 (LGA 1718), supports AMD Ryzen 7000 series processors
• 4 DIMM slots (2DPC), supports DDR5 ECC/non-ECC UDIMM
• 2 hot-swap 2.5" SATA drive bays
• 1 fixed 3.5" SATA drive bay or 1 Slim ODD
• 1 FHHL PCIe4.0 x16
• Supports 1 M.2 (PCIe5.0 x4), 1 M.2 (PCIe4.0 x4)
• 2 RJ45 (1GbE) by Intel® i210
• 1 HDMI, 1 DisplayPort
• Remote Management (IPMI)

Detail Specifications

• System
• Form Factor: 1U Rackmount
• Support MB
• B650D4U: Front Panel
• Buttons: Power, System Reset
• LEDs: Power, HDD Activity, LANs, System Event
• I/O Ports: 2 Type-A (USB3.2 Gen1)
• External Drive Bay / Storage
• Front Side Drive Bay:
• External: 2 hot-swap 2.5" SATA drive bays
• Internal: 1 fixed 3.5" SATA drive bay or 1 Slim ODD
• Internal Side:
• 1 M-key (PCIe5.0 x4), supports 2280/2242 form factor (CPU)
• 1 M-key (PCIe4.0 x4), supports 2280/2242 form factor (FCH)
• Power Supply
• Type: Single PSU
• Output Watts: 315W
• Efficiency: 80-PLUS Gold
• System Fan
• Fan: 3 PWM Hot-swap 40x56 mm fans, 1 PWM Hot-swap 40x28 mm fans
• Processor System
• CPU: Supports AMD Ryzen 7000 series Processors
• Socket: Single Socket AM5 (LGA 1718)
• Thermal Design Power: Up to 105W
• Chipset: AMD B650
• System Memory
• Supported DIMM Quantity: 4 DIMM slots (2DPC)
• Supported Type: DDR5 288-pin ECC/non-ECC UDIMM
• Max. Capacity per DIMM: 32GB
• Max. DIMM Frequency
• 5200 MHz (1DPC)
• 3600 MHz (2DPC)
• Voltage: 1.1V
• PCIe Expansion Slots (SLOT7 close to CPU)
• PCIe x 16: Rear: 1 FHHL PCIe4.0 x16 via RB1UX16_G4
