Gigabyte R163-Z35-ACH1 Rack Server - 1U EPYC9005 9004 Max.12x96GB 2x1300W

Product details

• Brand Name: Gigabyte
• SKU: 297922
• MPN: R163-Z35-ACH1

Features

• Single AMD EPYC™ 9005/9004 Series Processors
• 12-Channel DDR5 RDIMM, 12 x DIMMs
• Dual ROM Architecture
• 1 x 1Gbs LAN port via Intel I210-AT
• 12 x 2.5 Gen5 NVMeSATASAS-4 hot-swap bays
• 1 x M.2 slot with PCIe Gen3 x4 interface
• 2 x FHHL PCIe Gen5 x16 slots
• 2 x OCP NIC 3.0 PCIe Gen5 x16 slots
• Compatible with Supreme RAID by Grade Technology
• 1+1 1300W 80 PLUS Titanium redundant power supplies

CPU Supported

• CPU Type: AMD EPYC 9005 & 9004 Series
• CPU Socket: Socket SP5
• Installed CPU: No CPU Installed
• Max Processors: 1
• CPU Features: Single processor, cTDP up to 300W - At 25°C ambient, cTDP up to 400W

Memory Supported

• Memory Slots: 12 x 288Pin
• Installed Memory Size: No Memory Installed
• Memory Type Supported: DDR5 6000
• Channel Supported: 12 Channel

Storage Supported

• Installed HDD: No Storage Installed
• M.2:  1 x M.2 (2280/22110), PCIe Gen3 x4

Expansion Slots

• PCI Express:
  • 2 x FHHL PCIe Gen5 x16 slots
  • 2 x OCP NIC 3.0 PCIe Gen5 x16 slots

Communications

• First LAN: Intel I210-AT
• Max. LAN Speed: 1 Gigabit

Expansion Bays

• Hot-Swap Bays: 12 x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays

Power Supply

• Max. Power: 1+1 1300W 80 PLUS Titanium redundant power supplies

Environment

• Temperature:
  • Operating temperature: 10°C to 35°C
  • Non-operating temperature: -40°C to 60°C

Humidity:

• Operating humidity: 8%-80% (non-condensing)
• Non-operating humidity: 20%-95% (non-condensing)
