Supermicro MBD-H12SSL-CT-O Motherboard -Socket SP3 AMD EPYC7002 Max2TB DDR4 PCIE

Marketing Information

Key Features

• 1.Single AMD EPYC™ 7002 Series Processor
• 2.2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
• 3.Expansion slots:
•  5 PCI-E 4.0 x16
•  2 PCI-E 4.0 x8
•  M.2 Interface: 2 PCI-E 4.0 x4
•  M.2 Form Factor: 2280, 22110
•   M.2 Key: M-key
• 4.8 SATA3, Broadcom 3008 SAS3 (12 Gbps) controller for 8 SAS3 ports, 2 M.2
• 5.Dual 10GBase-T LAN via Broadcom BCM57416
• 6.ASPEED AST2500 BMC graphics
• 7.Up to 6 USB 3.0 ports  (4 rear + 2 via header)
• 8.7 PWM 4-pin Fans with tachometer status monitoring

Detail Specifications

• Physical Stats
• Form Factor: ATX
• Processor/Chipset
• CPU: Single AMD EPYCTM 7002 series Processor
• Socket SP3
• Cores: Up to 64 Cores
• Chipset: System on Chip
• System Memory
• Memory Capacity
• 8 DIMM slots
• Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM
• 8-channel memory bus
• Memory Type: DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
• DIMM Sizes: 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
• Memory Voltage: 1.2V
• Error Detection
• Corrects single-bit errors
• Detects double-bit errors (using ECC memory)
• On-Board Devices
• SATA
• SATA3 (6 Gbps)
• SAS
• Broadcom 3008 SAS3 (12 Gbps) controller
• RAID 0, 1, 10
• IPMI
• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
• ASPEED AST2500 BMC
• Network Controllers
• Dual 10GBase-T LAN via Broadcom BCM57416
• 1 Realtek RTL8211F PHY (dedicated IPMI)
• VGA
• ASPEED AST2500 BMC
• Input / Output
• SATA
• 8 SATA3 (6 Gbps) ports
• SAS
• 8 SAS3 (12 Gbps) ports
• LAN
• Dual 10GBase-T LAN ports
• 1 RJ45 Dedicated IPMI LAN port
• USB
• 6 USB 3.0 ports
• (4 rear + 2 via header)
• VGA
• 1 VGA port
• Others
• 1 COM port (rear)
• 2 SATA DOM power connectors
• 1 TPM 2.0 header
• Expansion Slots
• PCI-Express
• 5 PCI-E 4.0 x16
• 2 PCI-E 4.0 x8
• M.2
• Interface: 2 PCI-E 4.0 x4
• Form factor: 2280, 22110
• Key: M-key
• System BIOS
• BIOS Type
• AMI 256Mb SPI Flash EEPROM
• BIOS Features
• Plug and Play (PnP)
• DMI 2.3
• PCI 2.2
• ACPI 5.1
• USB Keyboard Support
• SMBIOS 3.1.1

Warranty Information

• 1 Year from Supermicro
