Supermicro MBD-H12SSL-I-O MB ATX AMD EPYC 7000 SP3 8xDDR4 G-ETH VGA SATA3 M.2

Key Features

• Single AMD EPYC™ 7003/7002 Series Processor (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
• 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
• Expansion slots:
  • 5 PCI-E 4.0 x16
  • 2 PCI-E 4.0 x8
  • M.2 Interface: 2 PCI-E 4.0 x4
  • M.2 Form Factor: 2280, 22110
  • M.2 Key: M-key
• 8 SATA3 or 2 NVMe via single SlimSAS x8
• 2 Gigabit Ethernet LAN Ports
• ASPEED AST2500 BMC graphics
• Up to 6 USB 3.0 ports (4 rear + 2 via header)
• 7 PWM 4-pin Fans with tachometer status monitoring

SPECIFICATIONS

SKU: MBD-H12SSL-I-O (This may ship in Retail Packing)

Physical Stats

• Form Factor: ATX
• Dimensions: 12" x 9.6" (30.5cm x 24.4cm)

Processor/Chipset

• CPU: Single AMD EPYC™ 7003/7002 Series Processor (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)
• Socket SP3
• Cores: Up to 64 Cores
• Chipset: System on Chip

System Memory

• Memory Capacity: 8 DIMM slots (Supports up to 2TB Registered ECC DDR4 3200MHz SDRAM
• 8-channel memory bus)
• Memory Type: DDR4 3200 MHz Registered ECC, 288-pin gold-plated DIMMs
• DIMM Sizes: 8GB, 16GB, 32GB, 64GB, 128GB, 256GB
• Memory Voltage: 1.2V
• Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices

• SATA: SATA3 (6 Gbps)
• IPMI
  • Support for Intelligent Platform Management Interface v.2.0
  • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
  • ASPEED AST2500 BMC
• Network Controllers
  • Dual gigabit LAN via Broadcom BCM5720
  • 1 Realtek RTL8211F PHY (dedicated IPMI)
• VGA: ASPEED AST2500 BMC

Input / Output

• SATA: 8 SATA3 (6 Gbps) ports
• SATA/NVMe Hybrid: 8 SATA3 or 2 NVMe via single SlimSAS x8
• LAN
  • 2 RJ45 Gigabit Ethernet LAN ports
  • 1 RJ45 Dedicated IPMI LAN port
• USB: 6 USB 3.0 ports (4 rear + 2 via header)
• VGA: 1 VGA port
• Others
  • 1 COM port (rear)
  • 2 SATA DOM power connectors
  • 1 TPM 2.0 header

Expansion Slots

• PCI-Express
  • 5 PCI-E 4.0 x16
  • 2 PCI-E 4.0 x8
• M.2
  • Interface: 2 PCI-E 4.0 x4
  • Form factor: 2280, 22110
  • Key: M-key

Chassis ( Optimized for H12SSL-i )

• 1U
  • SC813MFTQC-350CB2
  • SC813MFTQC-R407CB
• 2U
  • SC213BAC8-R1K23LPB
  • SC216BE1C4-R1K23LPB
  • SC825MBTQC-R802LPB
  • SC825TQC-R802LPB
  • SC826BE1C4-R1K23LPB
  • SCLA26AC12-R920LP1
• 3U
  • SC835TQC-R802B
  • SC836BE1C-R1K23B
• Mid-Tower: SC732i-903B
• Tower/4U
  • SC745BAC-R1K23B
  • SC846BE1C-R1K23B
• Server(s) ( with H12SSL-i )
  • AS -2014S-TR
  • AS -3014TS-i

System BIOS

• BIOS Type: AMI 256Mb SPI Flash EEPROM
• BIOS Features
  • Plug and Play (PnP)
  • DMI 2.3
  • PCI 2.2
  • ACPI 5.1
  • USB Keyboard Support
  • SMBIOS 3.1.1

Management

• Software
  • Super Doctor 5
  • Watch Dog
  • NMI
  • SUM
  • IPMI 2.0, KVM with dedicated LAN
• Power Configurations
  • ACPI Power Management
  • Power-on mode control for AC power loss recovery

PC Health Monitoring

• CPU
  • Monitors CPU Core Voltages, +3.3V, +5V, +5V standby, +3.3V standby
  • CPU switching voltage regulator
  • Supports system management utility
  • VBAT
• FAN
  • Up to 7-fan status tachometer monitoring
  • Up to 7 4-pin fan headers
  • Dual Cooling Zone
  • Status monitor for speed control
  • Pulse Width Modulated (PWM) fan connectors
• Temperature
  • Monitoring for CPU and chassis environment
  • CPU Thermal Trip Support
  • Thermal control for 7x Fan connectors
  • I²C Temperature Sensing Logic
• LED: CPU / System Overheat LED
• Other Features
  • Chassis Intrusion Detection
  • Chassis Intrusion Header
  • UID

Operating Environment / Compliance Specifications

• Operating Temperature:
  • 10°C to 35°C (50°F to 95°F)
• Non-operating Temperature:
  • -40°C to 70°C (-40°F to 158°F)
• Operating Relative Humidity:
  • 8% to 90% (non-condensing)
• Non-operating Relative Humidity:
  • 5% to 95% (non-condensing)
