Supermicro MBD-H13SAE-MF-O MB mATX AMD LGA1718 4xDIMM ETH DP HDMI SATA M.2 TPM

Key Features

• AMD EPYC™ 4004 series, Ryzen™ 9000 & 8700G* & 7000 Series Desktop Processors
• single socket LGA-1718 (socket AM5), up to 170W.
• Up to 192GB ECC/non-ECC Unbuffered DIMM, DDR5-5200MHz, in 4 DIMM slots.
• 2 PCIe 5.0 x16 (16/NA or 8/8), support up to 2 GPU cards(mechanical is up to 1 triple-width GPU card or 2 double-width GPU cards)
• 1 PCIe 4.0 x4
• 2x 1Gbit LAN port(i210 AT); a dedicated Realtek 1Gbit LAN for IPMI.
• Micro-ATX form factor
• 1 USB 3.2 Gen2x2 ports (type C, 20Gb, rear); 5 USB 3.2 Gen2 ports(2 Type C, rear, support DP 1.4 Alt mode)
• 1 HDMI 2.0 port, 1 DP 1.4a port

SPECIFICATIONS

Product SKU: MBD-H13SAE-MF (This model may ship in Retail Packaging)

Physical Stats

• Form Factor: Micro-ATX
• Dimension: 9.6" x 9.6" (24.384cm x 24.384cm)

Processor

• CPU
  • AMD EPYC™ 4004 series, Ryzen™ 9000 & 8700G & 7000 Series Desktop Processors
  • Single Socket LGA-1718 (Socket AM5) supported, CPU TDP supports Up to 170W TDP
• Core: Up to 16 cores, 32 threads

System Memory

• Memory Capacity: 4 DIMM slots
• Memory Type: 5200/4800/3600 MT/s Up to 192GB of memory with speeds of up to 5200MT/s (1DPC)/ 3600MT/s (2DPC)
• DIMM Sizes: 8GB, 16GB, 24GB, 32GB, 48GB
• Memory Voltage: 1.1V

On-Board Devices

• Chipset: B650
• SATA: 4 SATA3 ports; RAID 0,1,10
• IPMI: ASPEED AST2600 BMC
• Audio: ALC 888S HD Audio
• Network Controllers
  • Dual LAN with Intel® i210 Gigabit Ethernet Controller
  • Single LAN with ASPEED AST2600 BMC, Dedicated LAN for IPMI

Input / Output

• USB
  • 1 USB 3.2 Gen2x2 port(s) (1 rear type C 20Gb)
  • 5 USB 3.2 Gen2 port(s) (3 rear type A 10Gb; 2 rear type C DP 1.4 Alt mode)
  • 2 USB 3.2 Gen1 port(s) (2 headers 5Gb)
  • 1 USB 2 port(s) (1 via header 2 ports by a header)
• Video Output: 1 HDMI 2.0 port(s), 1 DP 1.4a port(s), 2 rear type C port(s) DP 1.4 Alt mode
• Serial Port: 1 COM Port(s) (1 header)
• TPM: 1 TPM Header

Expansion Slots

• PCIe
  • 1 PCIe 4.0 x4,
  • 2 PCIe 5.0 x16 slots (16/NA or 8/8)
• M.2
  • M.2 Interface: 2 PCIe 5.0 x4, RAID 0 & 1
  • Form Factor: 2280/22110
  • Key: M-Key

System BIOS

• BIOS Type: AMI 32MB SPI Flash EEPROM
• BIOS Features
  • ACPI 6.4
  • SMBIOS 3.5 or later
  • UEFI 2.8
  • Plug and Play (PnP)
  • USB Keyboard support

Management

• Software: SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Plug-ins for 3rd Party Software, IPMI Utilities
• Power Configurations: Power-on mode control for AC power loss recovery, Power button override mechanism, S3/S4/S5

Security

• Hardware: Trusted Platform Module (TPM) 2.0

PC Health Monitoring

• Voltage: System temperature, PCH temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support
• FAN: 7x 4-pin fan headers (up to 7 fans)

Operating Environment

• Operating Temperature Range: 0°C - 50°C (32°F - 122°F)
• Non-Operating Temperature Range: -20°C - 60°C (-4°F - 140°F)
• Operating Relative Humidity Range: 10% - 85% (non-condensing)
• Non Operating Relative Humidity Range: 10%

Unless specified, all Supermicro products are shipped in Brown Boxes and are NOT in Retail packs. Manuals and Guides are available from the official Supermicro website.
