Supermicro MBD-H13SVW-N-B Proprietary WIO Motherboard, AMD EPYC 8004 series

MPN: MBD-H13SVW-N-B

Main Features

• Physical Stats
• Form Factor: Proprietary WIO
• Dimension: 8.15" x 13.05" (20.7cm x 33.15cm)
• Processor
• CPU:
• AMD EPYC 8004 series Processors
• Single Socket SP6 supported, CPU TDP supports Up to 225W TDP
• Core: Up to 64 cores, 128 threads
• System Memory
• Memory Capacity:
• 6 DIMM slots
• Up to 768GB ECC Registered RDIMM, DDR5-4800MT/s
• Memory Type:
• 4800 MT/s ECC DDR5
• Max Memory (1DPC): Up to 768GB 4800MT/s ECC DDR5 RDIMM
• DIMM Sizes: 16GB, 32GB, 64GB, 96GB, 128GB
• Memory Voltage: 1.1V
• Error Detection:
• Corrects single-bit errors
• Detects double-bit errors (using ECC memory)
• On-Board Devices
• Chipset: System on Chip
• Network Controllers:
• Dual LAN with Broadcom BCM5720 1GBase-T
• Single LAN with Realtek RTL8211F PHY
• Input / Output
• USB: 6 USB 3.0 port(s) (4 USB; 2 via header)
• Video Output: 1 VGA port(s)
• TPM: 1 TPM Header
• Others:
• 3 MCIO (PCIe 5.0 x8) Port(s)
• 2 MCIO (PCIe 5.0 x8/SATA3) Port(s)
• Expansion Slots
• PCIe:
• 1 PCIe 5.0 x16 Right Riser Slot
• 1 PCIe 5.0 x32 Left Riser Slot
• M.2:
• M.2 Interface: 2 PCIe 3.0 x4
• Form Factor: 2280/22110
• Key: M-Key
• System BIOS
• BIOS Type: AMI 32MB SPI Flash EEPROM
• BIOS Features:
• ACPI 6.4
• SMBIOS 3.5 or later
• UEFI 2.8
• Plug and Play (PnP)
• USB Keyboard support
• Management
• Software: SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), Supermicro SuperDoctor 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Plug-ins for 3rd Party Software, IPMI Utilities
• PC Health Monitoring
• Voltage: VBAT, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, VRM temperature, CPU thermal trip support, 1.8V standby
• LED:
• UID/Remote UID
• BMC/IPMI Heartbeat LED
• Other Features: RoT
• FAN: 6x 4-pin fan headers (up to 6 fans)
• Operating Environment
• Operating Temperature Range: 10°C - 35°C
• Non-Operating Temperature Range: -40°C - 70°C
• Operating Relative Humidity Range: 8% - 90% (non-condensing)
• Non Operating Relative Humidity Range: 5% - 95% (non-condensing)
