Asus RNUC14RVHU50000UI NUC 5-125H DDR5 M.2 WF BT 2.5G-LAN DP HDMI MiniPC BarBone

General Information

• Manufacturer: ASUS Computer International
• Manufacturer Part Number: RNUC14RVHU50000UI
• Brand Name: Asus
• Product Line: NUC 14 Pro
• Product Model: NUC14RVHu5
• Product Name: NUC 14 Pro Barebone System
• Product Type: Barebone System

Technical Information

• AI-powered: Yes

Processor

• Number of Processors Installed: 1
• Processor Socket: Socket BGA-2049
• Processor Manufacturer: Intel
• Processor Type: Core Ultra 5
• Processor Generation: 14th Gen
• Processor Model: 125H
• Processor Core: Tetradeca-core (14 Core)
• Processor Speed: 1.20 GHz
• Maximum Turbo Speed: 4.50 GHz
• 64-bit Processing: Yes

Chipset

• Chipset Manufacturer: Intel

Memory

• Maximum Memory Supported: 96 GB
• Memory Technology: DDR5 SDRAM
• Memory Standard: DDR5-5600/PC5-44800
• Total Number of Memory Slots: 2.0

Storage

• Supported Storage Drive Interfaces:
  • PCI Express NVMe 4.0
  • Serial ATA
• Supported Storage Drive Types:
  • HDD
  • SSD

Controller Type:

• NVMe
• Serial ATA

Display & Graphics

• Graphics Controller Manufacturer: Intel
• Graphics Controller Model: Arc Graphics
• Graphics Memory Technology: DDR5 SDRAM
• Graphics Memory Accessibility: Shared

Network & Communication

• Ethernet Technology: 2.5 Gigabit Ethernet
• Wireless LAN: Yes
• Wireless LAN Standard: IEEE 802.11ax
• Bluetooth: Yes
• Bluetooth Standard: Bluetooth 5.3

I/O Expansions

• Number of Total Expansion Bays: 1
• Number of M.2 Interfaces: 2
• Interfaces/Ports
• HDMI (Rear): Yes
• Total Number of USB Ports: 5
• Number of USB 3.2 Gen 2 Ports: 3
• USB Type-C (Front): Yes
• USB Type-C Detail: 1 x USB 3.2 Gen2x2 Type C (20Gbps)
• Network (RJ-45): Yes
• Number of Network (RJ-45) Ports: 1
• Number of SATA Interfaces: 1
• Number of Thunderbolt 4 Ports: 2

Operating System Supported:

• Linux
• Windows 11

Power Description

• Maximum Power Supply Wattage: 120 W

Physical Characteristics

• Color Family: Black
• Product Color: Black
• Form Factor: Mini PC
• Height: 2.1"
• Width: 5.7"
• Depth: 4.4"
• Weight (Approximate): 1.26 lb

Package Contents:

• NUC 14 Pro Barebone System
• Power Adapter
• Power Cord
• Warranty Card
• Quick Start Guide
• VESA Mount
• VESA Mount plate

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 3 Year from ASUS
