StarTech HSB1SATSASBA 5.25" to 3.5" HDD Hot Swap Bay Traless Aluminum Built BLK

Name: StarTech HSB1SATSASBA 5.25" to 3.5" HDD Hot Swap Bay Traless Aluminum Built BLK
Brand: Startech
SKU: INGaSTA 8Z4102 - HSB1SATSASBA
Price: 47.75 USD
Availability: InStock

$47.75 USD

Shipping calculated at checkout.

In stock: 10

Description

5.25 to 3.5 Hard Drive Hot Swap Bay - For 3.5" SATA/SAS Drives - Trayless - Aluminum

Hot-swap drives with ease, using this trayless mobile backplane for desktop PCs or servers

Warranty Information

Warranty

2 Years

Connector(s)

Drive Connectors

1 - 29 pin SAS SFF-8482 Female

Host Connectors

1 - SATA Data & Power Combo (7+15 pin)

Environmental

Operating Temperature

0°C to 50°C (32°F to 122°F)

Storage Temperature

-20°C to 60°C(-4°F to 140°F)

Humidity

Operating - 5~85% RH Non-condensing
Storage - 5~95%

Hardware

Front Door Key Lock

Yes

Fan(s)

Interface

SATA

Number of Drives

Drive Size

3.5in

Compatible Drive Types

SAS & SATA

Drive Installation

Removable

Indicators

LED Indicators

1 - Drive Power/Activity

Packaging Information

Shipping (Package) Weight

14.5 oz [412.0 g]

Package Quantity

Package Length

7.8 in [19.8 cm]

Package Width

6.2 in [15.8 cm]

Package Height

1.8 in [4.6 cm]

Performance

Maximum Data Transfer Rate

6 Gbps

Type and Rate

SATA/SAS 6 Gbps

Max Drive Capacity

Currently tested with up to 10TB 7200 RPM hard drive

Hot Swap Capability

Yes

Temperature Alarm

Physical Characteristics

Color

Black

Material

Aluminum

Max Drive Height

1.0 in [26.1 mm]

Product Length

7.1 in [17.9 cm]

Product Width

5.7 in [14.6 cm]

Product Height

1.5 in [3.9 cm]

Weight of Product

11.9 oz [336.0 g]

Power

Input Voltage

5V DC / 12V DC

Output Voltage

5 DC

Software

OS Compatibility

OS independent; No software or drivers required

What's in the Box

Included in Package

1 - backplane

1 - SATA data cable

2 - keys

4 - screws

1 - quick-start guide
