StarTech M2E1BRU31C USB-C 10G M.2 NVMe PCIe SSD Porta Alum Ext Enclosure Black

Name: StarTech M2E1BRU31C USB-C 10G M.2 NVMe PCIe SSD Porta Alum Ext Enclosure Black
Brand: Startech
SKU: INGaSTA 7TR226 - M2E1BRU31C
Price: 97.08 USD
Availability: InStock

$97.08 USD

Shipping calculated at checkout.

In stock: 2

Description

USB-C 10Gbps M.2 NVMe PCIe SSD Enclosure - Rugged Aluminum External M.2 PCIe M-Key Case IP67 Rated - 1GB/s Read/Write - Supports 2230/2242/2260/2280 - TB3 Compatible - Mac/PC - TAA

Rugged SSD Enclosure | Thunderbolt 3 Compatible | USB-C Cable Included

Warranty Information

Warranty

2 Years

Connector(s)

Drive Connectors

1 - M.2 (PCIe, M-Key, AHCI/NVMe, NGFF)

Host Connectors

1 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)

Environmental

Operating Temperature

5°C to 35°C (41°F to 95°F)

Storage Temperature

-20°C to 50°C (-4°F to 122°F)

Humidity

Humidity: 20% ~ 80% RH

Hardware

Interface

USB 3.2 Gen 2 10Gbps

Bus Type

USB 3.2 Gen 2 10Gbps

Number of Drives

Drive Size

22 mm - M.2 NVMe

Compatible Drive Types

M.2 (PCIe, NVMe, M-Key, NGFF)

Drive Installation

Fixed

Supported Drive Height(s)

2230

2242

2260

2280

Chipset ID

JMicron - JMS583

Indicators

LED Indicators

1 - Power / Blinking: Read & Write Activity

Packaging Information

Package Height

1.3 in [3.2 cm]

Package Length

6.9 in [17.4 cm]

Shipping (Package) Weight

9.0 oz [256.0 g]

Package Width

5.7 in [14.4 cm]

Package Quantity

Performance

Maximum Data Transfer Rate

10 Gbps

Type and Rate

USB 3.2 Gen 2 - 10 Gbit/s

UASP Support

Yes

TRIM Support

Yes

4Kn Support

Yes

S.M.A.R.T. Support

Type and Rate

NVMe (PCIe Gen 3)

General Specifications

Not compatible with M.2 SATA or AHCI based SSDs

MTBF

50,000 Hours

Physical Characteristics

Color

Black

Product Height

0.6 in [1.4 cm]

Product Length

1.8 in [4.5 cm]

Weight of Product

5.8 oz [164.0 g]

Product Width

4.1 in [10.5 cm]

Material

Aluminum

Cable Length

20.5 in [52 cm]

Power

Power Source

Bus Powered

Input Voltage

5V DC

Output Voltage

5 DC

Software

OS Compatibility

OS independent; No software or drivers required

Special Notes / Requirements

Note

Windows 7 and earlier Windows versions do not support TRIM and UAS with USB storage devices.

What's in the Box

Included in Package

1 - NVMe Enclosure

1 - 1.7 ft [52 cm] USB-C Cable

1 - Additional Drive Mounting Stand-off

1 - Torx Screw Driver

1 - Rubber Feet

1 - Quick Start Guide
