StarTech SDOCKU313 USB 3.1 to SATA Hard Drive Docking Station 2.5" 3.5" HDD SSD

Name: StarTech SDOCKU313 USB 3.1 to SATA Hard Drive Docking Station 2.5" 3.5" HDD SSD
Brand: Startech
SKU: INGaSTT 1C7595 - SDOCKU313
Price: 97.15 USD
Availability: InStock

$97.15 USD

Shipping calculated at checkout.

In stock: 1

Description

Single Bay USB 3.1 to SATA Hard Drive Docking Station, USB 3.1 (10 Gbps) Hard Drive Dock, External 2.5/3.5" SATA III HDD/SSD Docking Station, Top-Loading Hard Drive Bay

External SSD/HDD Docking Station | USB 3.2 Gen 2 (10 Gbps) to SATA

Warranty Information

Warranty

2 Years

Connector(s)

Drive Connectors

1 - SATA Data & Power Combo (7+15 pin)

Host Connectors

1 - USB 3.2 USB Type-B (9 pin, Gen 2, 10 Gbps)

Environmental

Operating Temperature

5°C to 35°C (35°F to 95°F)

Storage Temperature

-20°C to 50°C (-4°F to 122°F)

Humidity

20% ~ 80% RH

Hardware

Interface

USB 3.2 Gen 2

Bus Type

USB 3.2 Gen 2

Number of Drives

Drive Size

2.5in & 3.5in

Compatible Drive Types

SATA

Drive Installation

Removable

Number of 2.5 inch bays

Fan(s)

Chipset ID

ASMedia - ASM235CM

Indicators

LED Indicators

1 - Power & Activity

Packaging Information

Package Height

6.6 in [16.8 cm]

Package Length

6.4 in [16.2 cm]

Shipping (Package) Weight

1.7 lb [0.8 kg]

Package Width

3.7 in [9.4 cm]

Package Quantity

Performance

Maximum Data Transfer Rate

10 Gbps

Type and Rate

USB 3.2 Gen 2 - 10 Gbit/s

UASP Support

Yes

4Kn Support

Yes

Type and Rate

SATA III (6 Gbps)

TRIM Support

Yes

Max Drive Capacity

Currently tested with hard drives up to 16TB at 7200 RPM

Physical Characteristics

Weight of Product

13.8 oz [392 g]

Color

Black

Material

Plastic

Product Length

5.7 in [14.5 cm]

Product Width

3.6 in [9.3 cm]

Product Height

2.5 in [6.4 cm]

Power

Power Source

AC Adapter Included

Input Voltage

100 - 240 AC

Input Current

0.6

Output Voltage

12V DC

Output Current

Center Tip Polarity

Positive

Plug Type

Power Consumption (In Watts)

Software

OS Compatibility

OS independent; No software or drivers required

Special Notes / Requirements

Note

Windows 7 and earlier Windows versions do not support TRIM with USB to SATA devices.

What's in the Box

Included in Package

1 - USB 3.1 HDD Dock

1 - USB 3.1 A to B cable - 40.5 inches

1 - Universal Power Adapter - 50 inches (cable)

4 - Power Adapter Plugs (NA,EU,UK,ANZ)

1 - Quick Install Guide
