SUPERMICRO MBD-X11SAE-B - Motherboard - ATX - LGA1151 Socket - C236 Chipset

SKU: 177028
MPN: MBD-X11SAE-B

Detail Specifications:

• Form Factor
• ATX
• CPU
• Single Socket H4 (LGA 1151) supports:
• Intel Xeon processor E3-1200 v5,
• Intel 6th Gen CoreTM i7/i5/i3,
• Intel Pentium,
• Intel Celeron processors
• CPU TDP up to 95W
• Memory Capacity
• 4x 288-pin DDR4 DIMM slots>
• Up to 64GB DDR4 ECC UDIMM
• Memory Type
• 2133/1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin (UDIMM) gold-plated DIMMs
• DIMM Sizes
• 16GB, 8GB, 4GB
• Memory Voltage
• 1.2 V
• Error Detection
• Corrects single-bit errors
• Detects double-bit errors (using ECC memory)
• Chipset
• Intel C236 chipset
• SATA
• SATA3 (6Gbps) via C236 controller
• RAID 0, 1, 5, 10 support
• Network Controllers
• Intel I210-AT + Intel PHY i219LM Ethernet Controllers
• Virtual Machine Device Queues reduce I/O overhead
• Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
• Audio
• ALC 888S HD Audio
• Input / Output
• SATA : 8x SATA3 (6Gbps) ports
• LAN : 2x RJ45 Gigabit Ethernet LAN ports
• USB : 6x USB 3.0 ports (2 rear + 4 via headers) , 8x USB 2.0 ports (2 rear + 6 via headers) , 2x USB 3.1 (rear)
• Video : 1 DVI - D, 1 DP (Display Port), 1 HDMI
• Audio : 7.1 HD Jacks
• Serial Port / Header : 2x COM ports (2 headers)
• SuperDOM : 2x SuperDOM (Disk on Module) ports with built-in power
• TPM : 1x TPM 1.2 20-pin Header
• PCI-Express
• 2x PCI-E 3.0 x16 slots (run at 16/NA or 8/8)
• 3x PCI-E 3.0 x1 slots
• 2x 5V PCI 32bit slots
• BIOS Type
• 128Mb SPI Flash EEPROM with AMI BIOS
• BIOS Features
• Plug and Play (PnP)
• APM 1.2
• DMI 2.3
• PCI 2.3
• ACPI 1.0 / 2.0 / 3.0 / 4.0
• USB Keyboard support
• Hardware BIOS Virus protection
• SMBIOS 2.7.1
• UEFI 2.3.1
• RTC (Real Time Clock) Wakeup
• Software
• AMT
• SuperDoctor 5
• vPro
• Watch Dog
• Power Configurations
• ACPI Power Management
• Keyboard Wakeup from Soft-Off
• CPU Fan auto-off in sleep mode
• Power-on mode for AC power recovery
• Voltage
• Monitors for CPU Cores, +3.3V, +5V, +12V, +5V Standby, VBAT, HT, Memory, Chipset Voltages.
• FAN
• Total of 5 fan headers supporting up to 5 fans
• 5 fans with tachometer status monitoring
• Status monitor for speed control
• Status monitor for on/off control
• Low noise fan speed control
• Pulse Width Modulated (PWM) fan connectors
• Temperature
• Monitoring for CPU and chassis environment
• CPU thermal trip support
• 12C temperature sensing logic
• Thermal Monitor 2 (TM2) support
• PECI
• LED
• CPU / System Overheat LED
• Suspend static indicator LED
• UID/Remote UID
• Other Features
• Chassis intrusion detection
• Chassis intrusion header
• Chipkill support
• RoHS

Warranty Information:
1 Year from Supermicro
