Supermicro MBD-X13DEI-T-B MB eATX LGA4677 16xDDR5 C741 G-ETH VGA SATA3 COM TPM

Key Features

• Support CXL
• 5th/4th Gen Intel® Xeon® Scalable processors, Dual Socket LGA-4677 (Socket E) , CPU TDP supports up to 350W TDP
• Intel® C741 Chipset
• Up to 4TB 3DS ECC RDIMM, DDR5-5600MT/s in 16 DIMM slots
• 4 PCIe 5.0 x16
• 2 PCIe 5.0 x8
• Broadcom BCM57416 Dual ports 10G LAN
• 6 USB3.0 and 3 USB2.0
• 2 SATA DOM ports
• 2 M.2
• 6 NVMe ports PCIe 5.0 x4 via 3 MCIO connectors
• 8 SATA3.0 ports

SPECIFICATIONS

Product SKU: MBD-X13DEI-T

Physical Stats

• Form Factor: EATX
• Dimension: 12.1" x 13.05" (30.74cm x 33.15cm)

Processor

• CPU
  • 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
  • Dual Socket V0 (LGA-4677) supported, CPU TDP supports Up to 350W TDP
• Core: Up to 64 cores

System Memory

• Memory Capacity
  • 16 DIMM slots
  • Up to 4TB 3DS ECC RDIMM, DDR5-5600MT/s
• Memory Type: 5600/5200/4800/4400/4000 MT/s ECC DDR5 RDIMM (3DS) Up to 256GB of memory with speeds of up to 5600MT/s(1DPC)
• DIMM Sizes: 16GB, 32GB, 64GB, 96(XCC Only)GB, 128GB, 256GB
• RDIMM: Up to 256GB
• Memory Voltage: 1.1V
• Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)

On-Board Devices

• Chipset: Intel® C741
• SATA
  • Intel® C741 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
  • Intel® C741 controller for 2 SATA3 (6 Gbps) ports; RAID 0,1
• IPMI: ASPEED AST2600 BMC
• Network Controllers
  • Dual LAN
  • Dual LAN with Broadcom BCM57416 10GBase-T

Input / Output

• SATA
  • 8 SATA3 (6Gbps) port(s)
  • 2 SATA3 (6Gbps) port(s)
• LAN: 1 RJ45 Dedicated IPMI LAN port
• USB
  • 3 USB 2 port(s) (2 via header; 1 Type A)
  • 6 USB 3 port(s) (2 via header; 4 rear)
• Video Output: 1 VGA D-Sub Connector port(s)
• Serial Port: 2 COM Port(s) (1 header; 1 rear)
• TPM: 1 TPM Header
• Others: 3 MCIO PCIe 5.0 x8

Expansion Slots

• PCIe
  • 2 PCIe 5.0 x8,
  • 4 PCIe 5.0 x16
• M.2
  • M.2 Interface: 2 PCIe 4.0 x2
  • Form Factor: 2280/22110
  • Key: M-Key

System BIOS

• BIOS Type: AMI 32MB AMI UEFI
• BIOS Features
  • ACPI 6.4
  • SMBIOS 2.8/3.5
  • UEFI 2.8A
  • Plug and Play (PnP)
  • PCI FW 3.2

Management

• Software: SuperCloud Composer, Supermicro Server Manager (SSM), Supermicro Power Manager (SPM), Supermicro Update Manager (SUM), Supermicro SuperDoctor® 5 (SD5), Super Diagnostics Offline (SDO), Supermicro Thin-Agent Service (TAS), SuperServer Automation Assistant (SAA) New!, Plug-ins for 3rd Party Software, IPMI Utilities

Security

• Hardware: Trusted Platform Module (TPM) 2.0

PC Health Monitoring

• Voltage: System temperature, PCH temperature, Memory temperature, CPU temperature, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support, +3.3V standby, Veore, Vmem, Peripheral temperature, Platform Environment Control Interface (PECI)/(TSI)
• LED
  • UID/Remote UID
  • CPU / System Overheat LED
• Temperature
  • Monitoring for CPU and chassis environment
  • CPU thermal trip support
  • Thermal Monitor 2 (TM2) support
  • PECI
• FAN
  • 8x 4-pin fan headers (up to 8 fans)
  • Fan speed control
  • Overheat LED indication
  • 8x fans with tachometer monitoring
• Other Features: UID, Node Manager Support, M.2 NGFF connector, Control of power-on for recovery from AC power loss, Chassis intrusion detection, ACPI power management

Operating Environment

• Operating Temperature Range: 10°C - 35°C (50°F - 95°F)
• Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F)
• Operating Relative Humidity Range: 8% - 90% (non-condensing)
• Non Operating Relative Humidity Range: 5% - 95% (non-condensing)
