Supermicro MBD-X13SCH-F-O Motherboard - C266 LGA1700 Max128GB DDR5 MicroATX

Marketing Information

Key Features

• Intel® Xeon® E-2400 Series Processor, Pentium®* Processor, Single Socket LGA-1700 (Socket V0) supported, CPU TDP supports Up to 95W TDP
• Intel® C266 controller for 8 SATA3 (6 Gbps) ports; RAID 0,1,5,10
• Up to 128GB ECC Unbuffered DIMM, DDR5-4400MHz, in 4 DIMM slots
• 1 PCIe 5.0 x16, 2 PCIe 4.0 x4 ( in x8)
• I/O: 1 VGA, 2 COM, 1 TPM header
• M.2 Interface: 2 PCIe 4.0 x4
• M.2 Form Factor: 2280, 22110
• M.2 Key: M-Key
• Dual LAN with Intel® i210 Gigabit Ethernet Controller
• 5 USB 3.2 Gen1 ports (2 rear + 1 Type A + 2 via header)
• 6 USB 2.0 ports (2 rear + 4 via header)

Detail Specifications

• Product SKUs: MBD-X13SCH-F
• Physical Stats
• Form Factor: microATX
• Processor
• CPU: Intel Xeon E-2400/Pentium Processor
• Single Socket LGA-1700 (Socket V0) supported, CPU TDP supports Up to 95W TDP
• Pentium G7400 and G7400T
• Core: Up to 8 cores
• System Memory
• Memory Capacity: 4 DIMM slots
• Up to 128GB Unbuffered ECC UDIMM, DDR5-4400MHz
• Memory Type: 4400/4000/3600 MT/s Up to 128GB of memory with speeds of up to 4400MT/s (2DPC)
• DIMM Sizes: 8GB, 16GB, 32GB
• Memory Voltage: 1.1V
• Error Detection
• Corrects single-bit errors
• Detects double-bit errors (using ECC memory)
• On-Board Devices
• Chipset
• Intel C266
• SATA
• Intel C266 controller for 8 SATA3 (6 Gbps) ports
• RAID 0,1,5,10
• IPMI
• ASPEED AST2600 BMC
• Graphics
• 1 Aspeed AST2600 BMC port(s)
• Network Controllers
• Dual LAN with 1GbE with Intel I210
• b>Input / Output
• SATA
• 8 SATA3 (6Gbps) port(s) via Slimline SAS x8 connector
• LAN
• 2 RJ45 Gigabit Ethernet LAN ports
• 1 RJ45 Dedicated IPMI LAN port
• USB
• 6 USB 2.0 port(s) (4 via header 2 rear)
• 5 USB 3.2 Gen1 port(s) (2 via header, 2 rear, 1 type A)
• Video Output
• 1 VGA D-Sub Connector port(s)
• Serial Port
• 2 COM Port(s) (1 header 1 rear)
• TPM
• 1 TPM Header
• Expansion Slots
• PCIe
• 1 PCIe 5.0 x16,
• 2 PCIe 4.0 x4 (in x8 slot)
• M.2
• M.2 Interface: 2 PCIe 4.0 x4
• Form Factor: 2280/22110
• Key: M-Key
• System BIOS
• BIOS Type
• AMI 32MB AMI UEFI
• BIOS Features
• ACPI 6.4
• SMBIOS 3.5
• UEFI 2.8
• Plug and Play (PnP)
• PCI FW 3.3
• Management
• Software
• Redfish API, Supermicro Server Manager (SSM), Supermicro Update Manager (SUM), SuperDoctor 5, Super Diagnostics Offline, KVM with dedicated LAN , IPMI 2.0
• Power Configurations
• ACPI Power Management, Power-on mode control for AC power loss recovery, Power button override mechanism, Wake-On-LAN
• Security
• Hardware
• Trusted Platform Module (TPM) 2.0
• PC Health Monitoring
• Voltage
• VBAT, System level control, Supports system management utility, Monitors CPU voltages, Chipset Voltage, Chassis intrusion header, +5V standby, +5V, +3.3V, +12V, Memory Voltages, 7-fan status, +3.3V standby
• LED
• UID/Remote UID
• CPU / System Overheat LED
• Temperature
• Monitoring for CPU and chassis environment
• CPU thermal trip support
• PECI
• FAN
• 7x 4-pin fan headers (up to 7 fans)
• Fan speed control
• Overheat LED indication
• 7 fans with tachometer status monitoring
• Other Features
• WOL, UID, M.2 NGFF connector, Control of power-on for recovery from AC power loss, Chassis intrusion header, ACPI power management
• Operating Environment
• Operating Temperature Range
• 0oC - 50oC (32oF - 122oF)
• Non-Operating Temperature Range
• -40oC - 70oC (-40oF - 158oF)
• Operating Relative Humidity Range
• 8% - 90% (non-condensing)
• Non Operating Relative Humidity Range
• 5% - 95% (non-condensing)

Warranty Information

• 1 Year from Supermicro
