Supermicro MBD-X14SAE-O Motherboard - W880 LGA1851 Socket V1 Max128GB DDR5 ATX

Marketing Information

Key Features

• 1. Intel Core Ultra 9/7/5 Series Processor, Single Socket LGA-1851(Intel® V1 Socket) supported, CPU TDP supports Up to 125W TDP
• 2. Up to 256GB Unbuffered ECC/non-ECC UDIMM, DDR5-5600MHz, in 4 DIMM slots
• 3. M.2 Interface: 1 PCIe 4.0 x4 and 1 PCIe 5.0x4 (support M.2 Form Factor 2280 only)
• M.2 Form Factor: 2280/22110
• M.2 Key: M-Key
• 4. 2 M.2 slots (1 PCIe 4.0 x4 from PCH, support 2280/22110, and 1 PCIe5.0 x4 from CPU, support 2280)
• 5. 2 PCIe 5.0 x16 slots,
• 1 PCIe 4.0 x4 slot
• 6. A 2.5 Gigabit LAN with Intel® Ethernet i226LM LAN controller
• 7. A 1 Gigabit LAN with Intel® Ethernet i219LM LAN controller [AMT/vPro]
• 8. 1 HDMI 2.1*, 1 DP 2.1**, 1 Thunderbolt™ 4.0 Type-C®
• *Supports data rates of up to 10 Gbps **Supports data rates of up to 10 Gbps
• 9. Intel® W880 Controller for 8 SATA3 (6 Gbps) ports, RAID 0,1,5,10
• 10.Supports Thunderbolt 4
• 11. Onboard TPM2.0
• Optimized Servers
• SYS-532AW-C

Detail Specifications

• Physical Stats
• Form Factor: ATX
• Processor
• CPU: Intel CoreTM Ultra 9/7/5 Processors
• Single Socket V1 (LGA-1851) supported, CPU TDP supports Up to 125W TDP
• Core: Up to 24 cores
• System Memory
• Memory Capacity: 4 DIMM slots
• Up to 256GB Unbuffered ECC/non-ECC UDIMM, DDR5-5600MT/s
• Note: Supports up to 192GB of DDR5 UDIMM with speeds of up to 5600MT/s with one DIMM single rank, or 4400MT/s with two DIMM dual rank in four memory slots
• Memory Type: 5600 MT/s Up to 256GB of memory with speeds of up to 6400 MT/s(1DPC) or 5200 MT/s (2DPC)
• DIMM Sizes: 8GB, 12GB, 16GB, 24GB, 32GB, 48GB, 64GB
• UDIMM: 8GB, 12GB, 16GB, 24GB, 32GB, 48GB, 64GB
• Memory Voltage: 1.1V
• Error Detection
• Corrects single-bit errors
• Detects double-bit errors (using ECC memory)
• On-Board Devices
• Chipset
• Intel W880
• SATA
• 8 SATA3 ports, RAID 0,1,5,10
• 1 SATA3 ports
• Audio
• ALC 888S HD Audio
• Network Controllers
• Single LAN with Intel I226LM Ethernet Controller
• Single LAN with Intel PHY I219LM LAN controller, for AMT/vPro
• Input / Output
• SATA
• 8 SATA3 (6Gbps) port(s) Supports software RAID 0,1,5,10
• USB
• 3 USB 3.2 Gen2 port(s) (3 rear type A)
• 2 USB 3.2 Gen2x2 port(s) (1 rear type C, 1 via header)
• 2 USB 3.2 Gen1 port(s) (2 headers)
• 1 USB 4 port(s) (1 rear type C Intel ThunderboltTM 4)
• Video Output
• 1 DP (DisplayPort) port(s), 1 Intel ThunderboltTM 4 Type C (Shared w/ USB4/ DP2.1) port(s), 1 HDMI port(s) Supports up to 8K at 60Hz
• Serial Port
• 1 COM Port(s) (1 header)
• TPM
• TPM TPM 2.0 onboard
• Expansion Slots
• PCIe
• 1 PCIe 4.0 x4,
• 2 PCIe 5.0 x16 (support up to 16/NA or 8/8, slot 3 support bifurcation x4x4
• M.2
• M.2 Interface: 1 PCIe 5.0 x4, RAID 0 and 1, 1 PCIe 4.0 x4, RAID 0 and 1
• Form Factor: 2280, 2280/22110
• Key: M-Key, M-Key
• System BIOS
• BIOS Type
• AMI 32MB AMI UEFI
• BIOS Features
• ACPI 6.5
• SMBIOS 3.8 or later
• UEFI 2.9
• Management
• Software
• Supermicro Server Manager (SSM), Supermicro SuperDoctor 5 (SD5), Super Diagnostics Offline (SDO), SuperServer Automation Assistant (SAA) New
• PC Health Monitoring
• Voltage
• VBAT, System temperature, PCH temperature, Memory temperature, CPU temperature, 3.3V standby, 1.05 (PCH), +5V, +3.3V, +12V, CPU thermal trip support, UID, +1.8V CPU, Triple Cooling Zones
• FAN
• 7x 4-pin fan headers (up to 7 fans)
• Fan speed control
• 5 fans with tachometer status monitoring
• Overheat LED indication
• Other Features
• WOL, RoHS, CPU thermal trip support for processor protection, Control of power-on for recovery from AC power loss, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, Voltage and Frequency Overclocking
• Operating Environment
• Operating Temperature Range
• 0oC - 50oC (32oF - 112oF)
• Non-Operating Temperature Range
• -20oC - -60oC (-4oF - 140oF)

Warranty Information

• 1 Year from Supermicro
