StarTech 129N-USBC-KVM-DOCK Dual-Laptop USB-C KVM Docking Station - KVM Switch D
Regular price
$356.05 USD
Sale price
$356.05 USD
Description
Couldn't load pickup availability
StarTech 129N-USBC-KVM-DOCK Dual-Laptop USB-C KVM Docking Station - KVM Switch D
Current product
Current
Vendor:
Startech
StarTech 129N-USBC-KVM-DOCK Dual-Laptop USB-C KVM Docking Station - KVM Switch D
Regular price
$356.05 USD
Sale price
$356.05 USD
Options
Descriptions
Dual-Laptop USB-C KVM Docking Station, Dual Monitor 4K 60Hz DisplayPort Dock, 5-Port USB Hub, GbE, 90W/45W Power Delivery to Two Laptops, Windows/Mac, 2-Host KVM Dock - TAA
Share a dual 4K 60Hz workstation between two laptop computers through a USB Type-C connection
Warranty Information
Warranty
3 Years
Package Quantity
1
Connector(s)
External Ports
2 - USB 2.0 Type-A (4 pin, 480Mbps)
2 - USB 3.2 Type-A (9 pin, Gen 2, 10Gbps)
1 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)
1 - 3.5 mm Mini-Jack (3 Position)
1 - 3.5 mm Mini-Jack (2 Position)
2 - DisplayPort (20 pin)
1 - RJ-45
Host Connectors
2 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)
Environmental
Operating Temperature
-10°C to 45°C (14°F to 113°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
0~90% RH (Non-condensing)
Hardware
4K Support
Yes
Fast-Charge Port(s)
No
Displays Supported
2
Interface
USB 3.2 Gen 2 (10 Gbps)
Bus Type
USB-C
Compatible Lock Slot
Kensington Standard Slot (K-Slot)
Kensington Nano Slot
Industry Standards
DisplayPort 1.4
USB 3.2 Gen 2 (10 Gbps)
USB 2.0 (480Mbps)
USB Power Delivery Specification Rev. 3.0
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chipset ID
DisplayLink - DL6950
Genesys Logic - GL3590
Genesys Logic - GL9510
Parade - PS186
Realtek - RTL8211F
Indicators
LED Indicators
1 - Power LED (White): Illuminates When the Dock is Connected to a Power Source and Powered On
1 - LAN Port - Network Status LED (Green): Illuminates to Indicate an Ethernet Link is Active
1 - LAN Port - Network Activity LED (Amber): Blinks to Indicate Network Traffic
Packaging Information
Package Length
6.4 in [16.2 cm]
Package Width
11.1 in [28.3 cm]
Package Height
3.9 in [10.0 cm]
Shipping (Package) Weight
3.3 lb [1.5 kg]
Performance
Wake On Lan
Yes
Maximum Data Transfer Rate
USB 3.2 Gen 2 (10 Gbps)
Maximum Digital Resolutions
2x DisplayPort - 4096 x 2160p (4K) 60Hz
Type and Rate
USB 3.2 Gen 2 - 10 Gbit/s
UASP Support
Yes
Compatible Networks
10/100/1000 Mbps
PXE
No
Full Duplex Support
Yes
General Specifications
KVM Ports: 2
Rack-Mountable: No
On-Screen Display: No
IP Control: No
Port Selection Support: Push Button and Hot-Keys
MTBF
42,209 Hours
Physical Characteristics
Color
Space Gray
Product Length
8.8 in [22.4 cm]
Product Width
3.5 in [9.0 cm]
Product Height
1.6 in [4.0 cm]
Weight of Product
14.2 oz [402.0 g]
Material
Plastic
Power
Power Source
AC Adapter Included
Power Delivery
90W (to the active host computer ) / 45W (to the second computer)
Input Voltage
100 - 240 AC
Input Current
2.4 A
Output Voltage
20V DC
Output Current
9 A
Center Tip Polarity
Positive
Plug Type
CP (OD:7.4/ID:5.1/CPD:0.6)
Power Consumption (In Watts)
180
Software
OS Compatibility
Windows® 10, 10 ARM, 11, 11 ARM
macOS 10.15, 11.0, 12.0, 13.0, 14.0
Ubuntu 18.04, 20.04, 22.04
ChromeOS™
macOS 10.15, 11.0, 12.0, 13.0, 14.0
Ubuntu 18.04, 20.04, 22.04
ChromeOS™
Special Notes / Requirements
System and Cable Requirements
Up to two host devices with available USB-C ports (to support laptop charging the host device's USB-C port must support USB Power Delivery)
Note
USB 3.2 Gen 2 (10Gbps) is also known as USB 3.1 Gen 2 (10Gbps), USB 3.1
What's in the Box
Included in Package
1 - USB-C Docking Station
2 - 3.3 ft [1 m] USB-C Host Cables
1 - Universal Power Adapter with Attached 5 ft [1.6 m] DC Cable
2 - 6 ft [1.8 m] Regional Power Cables (NA/JP, ANZ)
1 - Quick-Start Guide
..
