StarTech P4AD122-KVM-SWITCH 4-Port DisplayPort KVM Switch 6x USB 3.5mm w Power
Regular price
$530.70 USD
Sale price
$530.70 USD
Regular price
$475.99 USD
Description
Couldn't load pickup availability
StarTech P4AD122-KVM-SWITCH 4-Port DisplayPort KVM Switch 6x USB 3.5mm w Power
Current product
Current
Vendor:
Startech
StarTech P4AD122-KVM-SWITCH 4-Port DisplayPort KVM Switch 6x USB 3.5mm w Power
Regular price
$530.70 USD
Sale price
$530.70 USD
Regular price
$475.99 USD
Options
Descriptions
4-Port DisplayPort KVM Switch, Single 4K 60Hz Monitor, 6x USB Ports, Push-Button & Hotkey Switching, DisplayPort 1.2, OS Independent, TAA Compliant
Share a mouse, keyboard, USB 5Gbps hub, audio output device, and 4K 60Hz DisplayPort display between four DisplayPort-enabled computers
Warranty Information
Warranty
2 Years
Connector(s)
Console Interface(s)
4 - USB 2.0 Type-A (4 pin, 480Mbps)
2 - USB 3.2 Type-A (9 pin, Gen 1, 5Gbps)
1 - 3.5mm Stereo Female 3 pos
1 - DisplayPort
1 - Barrel Power Connector (Size M, OD:5.50, ID: 2.10)
Host Connectors
4 - DisplayPort
4 - USB 3.2 Type-B (9 pin, Gen 1, 5Gbps)
4 - 3.5mm Stereo Female 3 pos
Environmental
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-10°C to 60°C (14°F to 140°F)
Humidity
0% ~ 80% RH
Hardware
Audio
Yes
KVM Ports
4
PC Interface
USB 3.2 Gen 1 (5Gbps)
PC Video Type
DisplayPort
Number of Monitors Supported
1
Cables Included
No
Chipset ID
GL3523
Indicators
LED Indicators
4 - Port Selection:
Solid Green - PC 1 ~ 4 connected (powered on)
Solid Red - Selected PC Port
Solid Green - PC 1 ~ 4 connected (powered on)
Solid Red - Selected PC Port
1 - Power LED:
Solid Green - KVM Switch is powered on
Solid Green - KVM Switch is powered on
Packaging Information
Package Height
3.4 in [8.7 cm]
Package Length
11.6 in [29.5 cm]
Shipping (Package) Weight
3.6 lb [1.6 kg]
Package Width
9.6 in [24.5 cm]
Performance
On-Screen Display
No
Video Revision
DisplayPort 1.2
IP Control
No
Hot-Key Selection
Yes
Maximum Data Transfer Rate
USB 5Gbps
Maximum Digital Resolutions
4096 x 2160 60Hz
Supported Resolutions
10-bit RGB
3840x2160 @ 60hz
3840x2160 @ 30hz
2560x1600 @ 60hz
2560x1600 @ 30hz
2560x1440 @ 60hz
2048x1536 @ 60hz
2048x1536 @ 30hz
1920x1440 @ 60hz
1920x1200 @ 60hz
1920x1080 @ 60hz
1680x1050 @ 60hz
1600x1200 @ 60hz
1600x1024 @ 60hz
1600x900 @ 60hz
1440x1080 @ 60hz
1366x768 @ 60hz
1360x768 @ 60hz
1280x1024 @ 60hz
1280x960 @ 60hz
1280x800 @ 60hz
1280x768 @ 60hz
1280x720 @ 60hz
1176x664 @ 60hz
1152x864 @ 60hz
1024x768 @ 60hz
800x600 @ 60hz
Other resolutions may be supported
3840x2160 @ 60hz
3840x2160 @ 30hz
2560x1600 @ 60hz
2560x1600 @ 30hz
2560x1440 @ 60hz
2048x1536 @ 60hz
2048x1536 @ 30hz
1920x1440 @ 60hz
1920x1200 @ 60hz
1920x1080 @ 60hz
1680x1050 @ 60hz
1600x1200 @ 60hz
1600x1024 @ 60hz
1600x900 @ 60hz
1440x1080 @ 60hz
1366x768 @ 60hz
1360x768 @ 60hz
1280x1024 @ 60hz
1280x960 @ 60hz
1280x800 @ 60hz
1280x768 @ 60hz
1280x720 @ 60hz
1176x664 @ 60hz
1152x864 @ 60hz
1024x768 @ 60hz
800x600 @ 60hz
Other resolutions may be supported
Wide Screen Supported
Yes
Audio Specifications
DisplayPort - 2 Channel Audio
Analog Stereo - 2 Channel Audio
Auto Scan
3, 8, 15 & 30 seconds
Port Selection Support
Push Button and Hotkeys
MTBF
130,000 Hours
Physical Characteristics
Color
Black
Product Height
1.7 in [4.4 cm]
Product Length
8.7 in [22.0 cm]
Weight of Product
2.3 lb [1.0 kg]
Product Width
5.1 in [13.0 cm]
Material
Metal
Power
Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
1.0A
Output Voltage
12V DC
Output Current
3A
Center Tip Polarity
Positive
Plug Type
M
Power Consumption (In Watts)
36W
Software
OS Compatibility
No Drivers or Software Required
What's in the Box
Included in Package
1 - KVM Switch
1 - Universal Power Adapter (NA/EU/UK/ANZ)
1 - Set of Rubber Feet
1 - Quick-Start Guide
..
