StarTech RKCONS1708K 8 Port Rackmount VGA KVM USB Console 17" 1U LCD w Cables
$1,523.17 USD $1,523.17 USD
Shipping calculated at checkout.
In stock: 1
Description

8 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 17" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support

KVM Console | 1U | VGA | 1280x1024 | Cables & Mounting Hardware Included

Warranty Information

Warranty
2 Years
Connector(s)
Console Interface(s)
1 - VGA (15 pin, High Density D-Sub)
2 - USB 2.0 Type-A (4 pin, 480Mbps)
Host Connectors
8 - VGA (15 pin, High Density D-Sub)
Other Interface(s)
1 - 15 Pin High Density D-Sub
Environmental
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
10 ~ 80% RH
Hardware
U Height
1U
Front Door Key Lock
No
Audio
No
Display Size
17"
Panel Type
Active Matrix TFT LCD
KVM Ports
8
PC Interface
USB
PC Video Type
VGA
Number of Monitors Supported
1
Rack-Mountable
Yes
Cables Included
Yes
Daisy-Chain
No
Indicators
LED Indicators
8 - Green/Red - Online/Selected LED
Packaging Information
Package Height
7.5 in [19.1 cm]
Package Length
30.6 in [77.7 cm]
Package Width
24.5 in [62.3 cm]
Package Quantity
1
Shipping (Package) Weight
43.0 lb [19.5 kg]
Performance
On-Screen Display
Yes
IP Control
No
Maximum Analog Resolutions
1280 x 1024
Supported Resolutions
Resolutions up to 1280 x 1024 @ 60Hz
Aspect Ratio
5:4
Response Time
5ms
Contrast Ratio
1000:1
Brightness
250 cd/m²
Color Depth
8-bit, 16.7M colors
Pixel Pitch Support
0.264 x 0.264 mm
Viewing Angle
170° (H), 160° (V)
Maximum Number of Users
1
Port Selection Support
Push Button, Hotkeys, and OSD (On Screen Display)
MTBF
50, 000 Hrs
Physical Characteristics
Color
Black
Material
Steel
Cable Length
6 ft
Product Length
24.5 in [62.3 cm]
Product Width
18.9 in [48.0 cm]
Product Height
16.5 in [42.0 cm]
Weight of Product
37.5 lb [17.0 kg]
Maximum Mounting Depth
35.4 in [90 cm]
Minimum Mounting Depth
22.0 in [56 cm]
Power
Power Source
International Power Cords
Input Voltage
100 - 240 AC
Input Current
1.5A
Power Consumption (In Watts)
17W
Special Notes / Requirements
Note
The minimum mounting depth of this rackmount console is less than the length of the console itself. Please consider the length of the rackmount console when evaluating if it will fit into your rack.
What's in the Box
Included in Package
1 - KVM console
8 - KVM cables
8 - M5 cage nuts
8 - M5 screws
5 - Power Cords (NA, JP, UK, EU, ANZ)
2 - Mounting Rails
1 - Quick-Start Guide

..

Shipping Notes:

All our StarTech products are normally shipped within 1-2 business days from any of our warehouse locations below:

  • Monrovia, CA 91016 (Most usual)
  • Fort Worth, TX 76155
  • Carol Stream, IL 60188
  • Moore, SC 29369
  • Hazelton, PA 18202
