StarTech RKCONS1916K 16 Port Rackmount VGA KVM USB Console 19" 1U LCD w Cables
Regular price
$1,992.32 USD
Sale price
$1,992.32 USD
Regular price
$1,820.99 USD
Description
StarTech RKCONS1916K 16 Port Rackmount VGA KVM USB Console 19" 1U LCD w Cables
Current product
Current
Vendor:
Startech
StarTech RKCONS1916K 16 Port Rackmount VGA KVM USB Console 19" 1U LCD w Cables
Regular price
$1,992.32 USD
Sale price
$1,992.32 USD
Regular price
$1,820.99 USD
Options
Descriptions
16 Port Rackmount KVM Console w/ 6ft Cables - Integrated KVM Switch w/ 19" LCD Monitor - Fully Featured 1U LCD KVM Drawer- OSD KVM - Durable 50,000 MTBF - USB + VGA Support
Control your server or KVM switch from a centralized rack-mount KVM console
Warranty Information
Warranty
2 Years
Connector(s)
Console Interface(s)
16 - VGA (15 pin, High Density D-Sub)
1 - VGA (15 pin, High Density D-Sub)
Host Connectors
1 - VGA (15 pin, High Density D-Sub)
Other Interface(s)
1 - VGA (15 pin, High Density D-Sub)
2 - USB 2.0 Type-A (4 pin, 480Mbps)
Environmental
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
10 ~ 80% RH
Hardware
U Height
1U
Front Door Key Lock
No
Audio
No
Display Size
19"
Panel Type
Active Matrix TFT LCD
KVM Ports
16
PC Interface
USB
PC Video Type
VGA
Number of Monitors Supported
1
Rack-Mountable
Yes
Cables Included
Yes
Daisy-Chain
No
Packaging Information
Shipping (Package) Weight
48,5 lb [22,0 kg]
Package Quantity
1
Package Length
30,7 in [77,9 cm]
Package Width
24,6 in [62,4 cm]
Package Height
7,3 in [18,5 cm]
Performance
IP Control
No
Maximum Analog Resolutions
1280 x 1024
Supported Resolutions
1024x768
1280x720 (High-definition 720p)
1280 x 1024
Lower resolutions are also supported
1280x720 (High-definition 720p)
1280 x 1024
Lower resolutions are also supported
Contrast Ratio
1000:1
Brightness
250 cd/m²
Color Depth
8-bit, 16.7M colors
Pixel Pitch Support
0.264 x 0.264 mm
Maximum Number of Users
1
MTBF
50, 000 Hrs
Physical Characteristics
Color
Black
Material
Steel
Product Length
25,3 in [64,3 cm]
Product Width
19,0 in [48,3 cm]
Product Height
1,7 in [4,3 cm]
Weight of Product
29,8 lb [13,5 kg]
Maximum Mounting Depth
35,0 in [89 cm]
Minimum Mounting Depth
23,8 in [60,5 cm]
Power
Power Source
International Power Cords
Input Voltage
100 - 240 AC
Input Current
1.5A
Power Consumption (In Watts)
23W
What's in the Box
Included in Package
1 - KVM console
16 - 6 ft [1.8 m] KVM cables
8 - M5 cage nuts
8 - M5 screws
5 - regional power cords (NA, JP, UK, EU, ANZ)
4 - mounting rails (variable lengths)
1 - quick-start guide
..
