StarTech SV231TDPU34K 2 Port Triple DisplayPort KVM USB 3.5mm Audio Switch Power
$530.70 USD $530.70 USD
Shipping calculated at checkout.
In stock: 1
Description

2 Port Triple Monitor DisplayPort KVM Switch - 4K 60Hz UHD HDR - Desktop DP 1.2 KVM with 2 Port USB 3.0 Hub (5Gbps) & 4x USB 2.0 HID Ports, Audio - Hotkey Switching - TAA

KVM with USB | Triple Monitor | TAA Compliant | USB 3.0 Hub | DisplayPort 1.2 | Digital & Analog Audio

Warranty Information

Warranty
2 Years
Connector(s)
Console Interface(s)
3 - 20 pin DisplayPort Female
2 - 9 pin USB 3.0 A Female
4 - USB Type-A (4 pin; HID Port) USB 1.1
1 - 3.5 mm Audio Female
Host Connectors
6 - 20 pin DisplayPort Female
2 - 9 pin USB 3.0 B Female
2 - 3.5mm Audio (4-Position, Speakers + Mic, CTIA)
Environmental
Operating Temperature
0℃~40℃
Storage Temperature
-10℃~60℃
Humidity
0%~80%
Hardware
Audio
Yes
Cables Included
No
Daisy-Chain
No
Number of Monitors Supported
3
KVM Ports
2
PC Interface
USB 3.2 Gen 1 (5Gbps)
PC Video Type
DisplayPort
Chipset ID
Genesys Logic - GL3523
Indicators
LED Indicators
2 - Green (Power/Sync)
2 - Red (Selected Host)
Packaging Information
Package Height
3.6 in [9.1 cm]
Package Length
7.4 in [18.9 cm]
Shipping (Package) Weight
3.2 lb [1.4 kg]
Package Width
9.4 in [23.8 cm]
Package Quantity
1
Performance
Auto Scan
3, 8, 15 & 30 seconds
MTBF
156 000 hrs
Port Selection Support
Push Button and Hotkeys
On-Screen Display
No
Video Revision
DisplayPort 1.2
IP Control
No
Hot-Key Selection
Yes
Wide Screen Supported
Yes
Audio Specifications
DisplayPort - 5.1 Channel Audio
DisplayPort - 2 Channel Audio
Analog Stereo - 2 Channel Audio
Physical Characteristics
Color
Black
Product Height
2.9 in [7.5 cm]
Product Length
6.3 in [16.0 cm]
Weight of Product
1.9 lb [0.9 kg]
Product Width
4.7 in [12.0 cm]
Material
Steel
Power
Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
1.0A
Output Voltage
12V DC
Output Current
3A
Center Tip Polarity
Positive
Plug Type
M
Power Consumption (In Watts)
36W
What's in the Box
Included in Package
1 - KVM Switch
1 - Universal Power Adapter (NA/JP, EU, UK, NZ)
4 - Rubber Feet
1 - Quick-Start Guide

..

Shipping Notes:

All our StarTech products are normally shipped within 1-2 business days from any of our warehouse locations below:

  • Monrovia, CA 91016 (Most usual)
  • Fort Worth, TX 76155
  • Carol Stream, IL 60188
  • Moore, SC 29369
  • Hazelton, PA 18202

…MJ5
