StarTech SV831DUSBU 8 Port VGA 2 USB KVM 1U Rack Switch w Power Adapter Brackets
Regular price
$411.56 USD
Sale price
$411.56 USD
Regular price
$364.99 USD
Description
Couldn't load pickup availability
StarTech SV831DUSBU 8 Port VGA 2 USB KVM 1U Rack Switch w Power Adapter Brackets
Current product
Current
Vendor:
Startech
StarTech SV831DUSBU 8 Port VGA 2 USB KVM 1U Rack Switch w Power Adapter Brackets
Regular price
$411.56 USD
Sale price
$411.56 USD
Regular price
$364.99 USD
Options
Descriptions
8 Port 1U Rackmount USB KVM Switch with OSD - TAA
Control up to 8 VGA and USB computers from a single keyboard, mouse and monitor
Warranty Information
Warranty
3 Years
Connector(s)
Console Interface(s)
2 - USB 2.0 Type-A (4 pin, 480Mbps)
1 - VGA (15 pin, High Density D-Sub)
Host Connectors
8 - VGA (15 pin, High Density D-Sub)
Environmental
Operating Temperature
5°C to 40°C (41°F to 104°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
80% RH
Hardware
Audio
No
KVM Ports
8
PC Interface
USB
PC Video Type
VGA
Number of Monitors Supported
1
Rack-Mountable
Yes
Cables Included
No
Daisy-Chain
Yes
Indicators
LED Indicators
8 - Red - Selected PC
1 - Green - Power
8 - Green - Online PC
Packaging Information
Package Quantity
1
Package Length
22.6 in [57.3 cm]
Package Width
3.5 in [8.9 cm]
Package Height
10.6 in [26.8 cm]
Shipping (Package) Weight
7.3 lb [3.3 kg]
Performance
On-Screen Display
Yes
IP Control
No
Hot-Key Selection
Yes
Maximum Analog Resolutions
1920 x 1440@60Hz (1920 x 1200@60Hz - Wide Screen)
Wide Screen Supported
Yes
Maximum Number of Users
1
Maximum Cascaded Computers
64
Port Selection Support
Push Button, Hotkeys, and OSD (On Screen Display)
MTBF
150000 hours
Physical Characteristics
Color
Black
Material
Steel
Product Length
17.2 in [43.8 cm]
Product Width
7.1 in [18.0 cm]
Product Height
1.8 in [4.5 cm]
Weight of Product
4.9 lb [2.2 kg]
Power
Power Source
AC Adapter Included
Input Voltage
100 - 240 AC
Input Current
0.6A
Output Voltage
12V DC
Output Current
1.5A
Center Tip Polarity
Positive
Plug Type
M
Power Consumption (In Watts)
18
Software
OS Compatibility
OS independent; No software or drivers required
What's in the Box
Included in Package
1 - 8 Port USB KVM Switch
2 - Mounting Brackets
1 - Bag of Screws
1 - Pack Rubber Feet
1 - Universal Power Adapter (NA/UK/EU)
1 - User Manual
..
