Elo E330620 2294L 21.5" Open FrameHDMI VGA DP IntelliTouch Multi Touch USB Clear

General Information

• Product Type: Open-frame LCD Touchscreen Monitor
• Manufacturer Part Number: E330620
• Packaged Quantity: 1
• Manufacturer: Elo Touch Solutions, Inc
• Product Model: 2294L
• Product Name: 2294L 21.5" Open Frame Touchscreen (Rev B)
• Brand Name: Elo

Technical Information

• Aspect Ratio: 16:9
• Response Time: 14 ms
• Features: On-screen Display (OSD)
• Mount Type: Flush Mount
• Viewable Screen Size: 21.5"
• Screen Mode: Full HD
• Horizontal Viewing Angle: 178°
• Vertical Viewing Angle: 178°
• Backlight Technology: LED
• Panel Technology: Thin Film Transistor (TFT)
• Curved Screen: No
• Screen Size Class: 22"

Power Description

• Operating Power Consumption: 25 W
• Standby Power Consumption: 1.50 W
• Off-Mode Power Consumption: 500 mW
• Energy Consumption per Year: 39 kWh

Video

• Contrast Ratio: 1,000:1
• Brightness: 250 Nit
• Color Supported: 16.7 Million Colors
• Maximum Resolution: 1920 x 1080

Interfaces/Ports

• USB: Yes
• HDMI: Yes
• HDMI Version: 1.3
• VGA: Yes
• DisplayPort: Yes
• USB Standard: USB 2.0
• DisplayPort Version: 1.1a

Physical Characteristics

• Weight (Approximate): 11.24 lb
• Height: 12.2"
• Width: 20.3"
• Depth: 1.5"
• VESA Mount Compatible: Yes
• VESA Mount Standard: 100 x 100
• Product Color: Black

Touchscreen Information

• Touchscreen Type: TouchPro Projected Capacitive
• Touchscreen: Yes
• Multi-touch Screen: Yes

Miscellaneous

• Package Contents:
• 2294L 21.5" Open Frame Touchscreen (Rev B)
• HDMI cable
• VGA Cable
• RJ45 OSD Remote
• Touch USB Cable
• User Manual CD
• Quick Install Guide
• Flush Mount Brackets w/Screws
• EEI Label
• Japan Class-B TM info sheet
• Certifications & Standards:
• TÜV
• Environmentally Friendly: Yes
• Mean Time Between Failures (MTBF): 5.7 Year
