Microchip PD-9001GI/DC Single Port 30W Industrial PoE Midspan Dual DC Gigabit

The single port PoE midspan provides up to 30 Watts of power over Ethernet and offers a IEEE 802.3at-compliant solution for remote powering of current and emerging high power applications. The PD-9001GI enables remote power for a new range of applications including 802.11n access points, pan-tilt zoom (PTZ) cameras and other IP terminals. It complies to IEEE 802.3at PoE standard and is backward compatible to IEEE 802.3af. It can power both 10/100Base-T network devices and 1000Base-T devices. The midspan is designed for industrial applications and outdoor applications from temperature point of view.

Product Features

• Number of ports: 1
• PoE output: 30W
• Data rates: 10/100/1000 Mbps
• Power input: DC
• Industrial rated: IP30
• Regulatory compliance: IEEE 802.3at (PoE), RoHS compliant, WEEE compliant, CE
• EMI: EN50522 Class A, EN55024
• Safety: UL 508
• Shock: IEC 60068-2-27 15g, 11 ms duration
• Freefall: IEC 60068-2-32
• Vibration: IEC 60068-2-6, 3, 5 mm, 3 Hz - 9 Hz, 10 cycles, 1 octave/min, 1g, 9 Hz – 150 Hz, 10 cycles 1 octave/min
• Compact design

Detail Specifications

• Data Rate: 1 Gbps
• Input Power: DC
• Managed: No
• Number of Ports: 1
• Operating Environment: Industrial
• Operating Humidity (%): 90
• Operating Temperature (oC): -40 to 75
• PoE Standard: IEEE 802.3at
• PoE Systems Type: Midspan
• Power Per Port: 30W
• Product Type: 30W PoE
• Rack Mountable: No
• Item Dimension (L inchxW inchxH inch): 7 x 5 x 2
• Weight: 1.41 lb
• Warranty Information: 3 Years from MicroChip
