Microchip PD-AS-951/12-24 Splitter 12V 24V Terminal via PoE 2x RJ45 Power Data

PD-AS-951 Splitter
Enables Powering of 12V and 24V Terminals via PoE

Microchip's PD-AS-951 splitter enables data terminals that were not originally designed to accept power from the Ethernet to be powered by Power over Ethernet (PoE) midspans. The PD-951 splitter can power devices such as WiMAX CPEs, small WiMAX base-stations, 802.11n access points, thin clients, Pan-Tilt-Zoom (PTZ) IP cameras, video phones and more.

The splitter is identified as a Powered Device (PD) in front of the powering Midspan and after being detected and powered, it physically splits the data and power streams, arriving over a single cable, into two separate cords (LAN and DC) which go directly to the data terminal. The DC output is user selectable (12V or 24V).

Features

• Splits power and data into individual power and data outputs
• User selectable 12V or 24V output
• Accepts IEEE® 802.3at/af PoE input

Specifications

• Number of Ports: 1
• Data Rate: 10/100/1000 Mbps
• Input Power Requirement: Input Voltage: 44 to 57 Vdc Input Power 70W Maximum
• Output Power: 54W Maximum 5A @ 12V; 2.5A @ 24V
• Pin Assignment: 1/2 (-), 3/6 (+) or 7/8 (-), 4/5 (+)
• Dimensions: L × W × H 2.87 in. × 5.11 in. × 1.50 in.
• Net Weight: 310g
• Connectors: 2 × RJ-45, Shielded, EIA 568A and 568B (DC O.D. × I.D. 2.5 × 6.4 mm)
• Indicators: Output Power Indicators: Green LED (4-pairs), Yellow LED (2-pairs)
• Hazardous Substances: CE, WEEE
• Warranty: 1 year
• Reliability: MTBF: 100,000 hrs. @ 25ºC
• Thermal Rating: 38 BTU/Hr
• Regulatory Compliance: IEEE^{®} 802.3af/at
• Electromagnetic Emission and Immunity:
  • FCC Part 15 Class A
  • EN55022 (CISPR 22), Class A
  • EN55024 (CISPR 24)
