StarTech NLWH-10F-CAT8-PATCH 10Ft CAT8 ETH Snagless Cable RJ45 25/40G PoE+ White

Name: StarTech NLWH-10F-CAT8-PATCH 10Ft CAT8 ETH Snagless Cable RJ45 25/40G PoE+ White
Brand: Startech
SKU: INGaSTA JS8690 - NLWH-10F-CAT8-PATCH
Price: 36.86 USD
Availability: InStock

$36.86 USD

Shipping calculated at checkout.

In stock: 1

Description

10ft White CAT8 Ethernet Cable, Snagless RJ45, 25G/40G, 2000MHz, 100W PoE++, S/FTP, 26AWG Pure Bare Copper Wire, LSZH, Shielded Network Patch Cord w/Strain Reliefs, Fluke Channel Tested

Connect reliably to a 25G/40G network using this Shielded LSZH Cat8 Cable

Product ID: NLWH-10F-CAT8-PATCH

Connect to a 25/40Gbps switch or networking device using this Snagless S/FTP Category 8 Ethernet Cable. The 2000MHz maximum frequency enables up to four times higher throughput than Cat6a.

Connector(s)

Connector A

1 - RJ-45

Connector B

1 - RJ-45

Environmental

Humidity

0% ~ 85% RH

Operating Temperature

0°C to 50°C (32°F to 122°F)

Storage Temperature

-20°C to 60°C (-4°F to 140°F)

Hardware

Active or Passive Adapter

Passive

Number of Conductors

4-Pair S/FTP - 8P8C

Connector Plating

Gold

Cable Jacket Material

Low Smoke Zero Halogen

Cable Shield Material

Aluminum-Mylar Tape with Braid

Cable Type

Shielded Snag-less

Wiring Standard

TIA/EIA-T568B

Industry Standards

IEEE 802.3ba 40GBASE-T

Packaging Information

Package Quantity

Package Length

8.7 in [22.0 cm]

Package Width

7.5 in [19.0 cm]

Package Height

0.8 in [2.0 cm]

Shipping (Package) Weight

4.7 oz [132.0 g]

Performance

Maximum Data Transfer Rate

40Gbps

Cable Rating

CAT8 - 2000 MHz

MTBF

Connectors rated beyond 750 mating cycles

Physical Characteristics

Color

White

Product Length

10.0 ft [3.0 m]

Product Width

0.5 in [1.2 cm]

Product Height

0.3 in [8.2 mm]

Weight of Product

4.3 oz [122.0 g]

Connector Style

Straight

Wire Gauge

26 AWG

Conductor Type

Solid Copper

Material

Metal and Plastic

Cable Length

10.0 ft [3.0 m]

Cable OD

0.2 in [5.6 mm]

Website Filters

Fire Rating

LSZH Rated (Low Smoke Zero Halogen)

What's in the Box

Included in Package

1 - 10ft White CAT8 Shielded Snagless Patch Cable

Shipping Notes:

All our StarTech products are normally shipped within 1-2 business days from any of our warehouse locations below:

Monrovia, CA 91016 (Most usual)
Fort Worth, TX 76155
Carol Stream, IL 60188
Moore, SC 29369
Hazelton, PA 18202
