Warranty

2 Years

PoE

Yes

Connector Type(s)

1 - Terminal Block (4 Wire)

4 - RJ-45 (PoE+)

1 - Ethernet Gigabit

Operating Temperature

-40°C to 75°C

Storage Temperature

-40°C to 85°C

Humidity

5 to 95% (non-condensing)

Ports

5

Industry Standards

IEEE 802.3 10/100/1000BASE-T
IEEE 802.3at PoE Plus
CSMA/CD
IEEE 802.3x Flow Control and Back Pressure

Chipset ID

Realtek RTL8367
IC Plus IP804AR

LED Indicators

4 - PoE

5 - Link / Active

2 - V1, V2 Power

Package Height

2.6 in [6.6 cm]

Package Length

8.5 in [21.6 cm]

Shipping (Package) Weight

14.2 oz [402.0 g]

Package Width

6.6 in [16.8 cm]

Package Quantity

1

Maximum Cable Length

328.0 ft [100 m]

Surge Protection

2kV

Auto MDIX

Yes

Full Duplex Support

Yes

Jumbo Frame Support

9K max.

General Specifications

ESD Standard: IEC 61000-4-2: Contact: 6KV; Air: 8KV
EFT Standard: IEC 61000-4-4: Power: 2KV; Signal: 2KV
Surge Standard: IEC 61000-4-5: Power: 2KV; Signal: 2KV
Vibration Standard: EN 60068-2-6
Shock Standard: EN 60068-2-27
Free-Fall Standard: EN 60068-2-32
Housing Standard: IP-30
Safety Standard: EN60950-1

MTBF

538451 hours

Color

Black

Form Factor

Industrial

Product Height

1.3 in [3.2 cm]

Product Length

4.1 in [10.4 cm]

Weight of Product

5.3 oz [150.6 g]

Product Width

3.2 in [8.2 cm]

Material

Steel

Power Consumption (In Watts)

Max. 126W

Patents and Licenses

United States Patent No. 5,406,260 (expired)
United States Patent No. 6,650,622
United States Patent No. 7,457,250
United States Patent No. 8,155,012
United States Patent No. 8,902,760
United States Patent No. 8,942,107
United States Patent No. 9,019,838
United States Patent No. 9,049,019
United States Patent Application No. 14/695,456
United States Patent Application No. 14/726,940

Included in Package

1 - Industrial Grade Ethernet Switch

1 - Terminal Block

1 - Mounting Hardware Kit

1 - Quick-Start Guide
