TP-Link DS111P Omaha 8x 100Mbps 3x Gbps Unmanaged Desktop Switch w 8 Port PoE+

DS111P
Omada 8-Port 10/100Mbps + 3-Port Gigabit Unmanaged Desktop Switch with 8-Port PoE+

• 8× 10/100 Mbps RJ45 Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port
• 8× PoE+ ports transfer data and power on individual cables
• Works with IEEE 802.3af/at compliant PDs
• Supports PoE Power up to 30 W for each PoE port
• Supports PoE Power up to 65 W for 8 PoE ports*
• Up to 250 m (802 ft) data and power transmitting range under Extend Mode**
• Isolation Mode allows one-click client traffic separation for higher security and performance
• PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
• Fanless Design reduces power consumption and works silently in its location
• Plug and Play. No configuration or central management required.

SPECIFICATION

HARDWARE FEATURES

• Interface
  • 8× 10/100 Mbps 802.3af/at PoE+ Ports, 2× Gigabit RJ45 Ports, 1× Gigabit SFP Port
  • AUTO Negotiation
  • AUTO MDI/MDIX
• Network Media
  • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
  • 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
  • EIA/TIA-568 100Ω STP (maximum 100m)
• Fan Quantity: Fanless
• Physical Security Lock: Yes
• External Power Supply: External Power Adapter (Output: 53.5 VDC / 1.31 A)
• Packet Forwarding Rate: 5.6544 Mpps
• PoE Ports (RJ45)
  • Standard: 802.3 af/at compliant
  • PoE Ports: Ports 1–8
  • Power Supply: 65 W
• Mac Address Table: 2K
• Jumbo Frame: 16 KB
• Switching Capacity: 7.6 Gbps
• Dimensions ( W x D x H ): 8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)
• Max Power Consumption
  • 5.61 W (220 V/50 Hz. no PD connected)
  • 77.32 W (110 V/50 Hz. with 65 W PD connected)
• Max Heat Dissipation
  • 19.13 BTU/h (no PD connected)
  • 263.7 BTU/h (with 65 W PD connected)

SOFTWARE FEATURES

• Transmission Method: Store-And-Forward
• Advanced Functions
  • Compatible With IEEE 802.3af/at Compliant PDs
  • Extend Mode: Ports 1–4/1–8**
  • Isolation Mode: Ports 1–8
  • PoE Auto Recovery: Ports 1–8
  • Mac Address Auto-Learning and Auto-Aging
  • IEEE802.3x Flow Control

OTHER INFORMATION

• Certification: FCC, CE, RoHS
• Environment:
  • Operating Temperature: 0–40 ℃ (32–104 ℉)
  • Storage Temperature: -40–70 ℃ (-40–158 ℉)
  • Operating Humidity: 10–90% RH non-condensing
  • Storage Humidity: 5–90% RH non-condensing

PACKAGE CONTENTS

• DS111P
• Power Adapter
• Installation Guide
• Rubber Feet
