TRENDnet TE100-S80g 8 Port 10/100 Mbps GREENnet Metal Case Desktop Switch

​General Information

• SKU    82937
• Vendor:  TRENDnet
• MPN:  TE100-S80G

Marketing Information

Trendnet Network Device TE100-S80g 8-Port 10/100Mbps GREENnet Switch Retail

The compact 8-Port 10/100Mbps GREENnet Switch (model TE100-S80g) provides improved bandwidth performance, ease of use and reliability, all while reducing power consumption by up to 40%.GREENnet technology automatically adjusts power voltage as needed, resulting in substantial energy savings. Embedded GREENnet technology works right out of the box with no management required. Boost your office efficiency and reduce network congestion with a total switching capacity of 1.6Gbps with Full-Duplex Mode. Plug and Play this sturdy metal switch for reliable high-speed network connectivity.

Key Features

• MAC Address Table Size - 1K entries
• Power Device - Power Adapter - External
• Ports Qty - 8 Ports
• RAM - 768KB
• Data Transfer Rate - Ethernet 10M/20Mbps (half/full duplex), Fast Ethernet 100M/200M (half/full duplex)
• Data Link Protocol - CSMA/CD, Star
• Compliant Standards - IEEE 802.3 10Base-T / IEEE 802.3u 100Base-TX / IEEE 802.3x Flow Control

Detail Specifications

• IEEE 802.3 10Base-T / IEEE 802.3u 100Base-TX / IEEE 802.3x Flow Control
• Ethernet: UTP/STP Cat. 3, 4, 5 up to 100m
• Fast Ethernet: UTP/STP Cat. 5, 5e, 6 up to 100m
• Ethernet: 10Mbps/20Mbps (half/full-duplex)
• Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)
• Power Consumption: 2.5W (max)
• Switch Fabric: 1.6Gbps forwarding capacity
• Interface: 8 x 10/100Mbps Auto-MDIX RJ-45 Ports
• Packaging Dimension: 10 x 8 x 3 inch (HxWxD)
• Weight: 1.76 lbs
