Chenbro RM24508H02*15167 RM245 Series 2U High Flexible Storage Server Chassis

MPN: RM24508H02*15167

Main Features

• MB Form Factor: ATX (12" x 9.6")
• Dimension (D x W x H)
• 557.6 x 438.0 x 87.0 (mm)
• 21.95" x 17.24" x 3.43"
• Drive Bay
• RM24508 (3.5" Hot-swap): 8
• RM24508 (Slim ODD): 1
• RM24508 (Internal 2.5"): 2
• RM24512 (3.5" Hot-swap): 12
• Option (2.5" Hot-swap, Rear) for OS or Cache: 2
• RM24500 (5.25" Open-bay): 2
• RM24504 (5.25" Open-bay): 2
• RM24504 (3.5" Hot-swap): 4
• Storage Backplane
• RM24504: 3.5" 4-port 12Gbps, Mini-SAS HD
• RM24508: 3.5" 8-port 12Gbps, Mini-SAS HD
• RM24512: 3.5" 12-port 12Gbps, Mini-SAS HD
• Passive or Active
• PSU Form Factor: 2U Single or 1+1 CRPS
• Indicator
• 1 x Power Status
• 2 x LAN Activity
• 1 x HDD Status
• 1 x UID
• 1 x System Alarm
• Front Control
• 1 x Power On/Off
• 1 x System Reset
• 1 x UID
• 2 x USB3.0
• Cooling Fan: Middle: 80 x 38 mm (3, up to 4), Hot-swap
• System Security: Intrusion Switch (Option)
• Expansion Slot Opening: 3 x Full Height or 7 x Low Profile
• Net Weight: 9.5 kg/20.93 lb
• Gross Weight: 12.0 kg/26.43 lb
• Cubic Feet: 2.89
• Container Loading (Single Packing): 20': 260, 40': 560, 40'H: 616

Our Chenbro products are shipping from any of the following locations:

• Monrovia, CA 91016 (Most usual)
• San Jose, CA 95132
• Hanover Park, IL 60133
• Miami, FL 33122
• Edison, NJ 08837

International orders may take an additional 2 to 3 days.
