NZXT CM-H72FW-R1 H7 Flow RGB Fan Mid Tower ATX Airflow PC Case Steel Glass White

Marketing Information

The H7 Flow RGB revolutionizes GPU cooling in a classic mid-tower form factor. Its vertical PSU layout allows space for 3 x 120mm bottom fans, offering efficient cooling without expanding the case footprint.

• Supports three bottom-mounted 120mm fans for direct GPU cooling while retaining a narrow mid-tower footprint.
• Comes equipped with a F360 RGB Core single-frame fan for exceptional out-of-the-box cooling and RGB lighting.
• High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.
• Supports up to 420mm radiators in the front and 360mm radiators in the top for powerful cooling potential.
• Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.
• Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.
• Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.
• Tool-less access to the front, top, and side panels makes building and upgrading a breeze.

Detail Specifications

Key Specs

• Motherboard Support:E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
• Enclosure Type:Mid-Tower
• Case Material:SGCC Steel, Ultra-Clear Tempered Glass (White)

Compatibility and Clearance

• CPU Cooler Height:Up to 185mm
• GPU Length:Up to 410 mm
• PSU Length:Up to 200 mm
• Cable Management:Up to 34.5 mm
• Top Mounted 140mm / 280mm Radiator and Fan Combined Thickness:Up to 57 mm

Front I/O Ports

• USB 3.2 Gen 1 Type-A:2
• USB 3.2 Gen 2x2 Type-C (20 Gbps):1
• Headset Audio Jack:1

Expansion Slots

• Standard:7
• Vertical:0

Drive Bays

• 2.5":2+2
• 3.5":2

Fan Support

• Front:3 x 120 mm / 3 x 140 mm (1 x F360 RGB Core included)
• Top:3 x 120 mm / 2 x 140 mm
• Bottom:3 x 120 mm
• Rear:1 x 120 mm / 1 x 140 mm
• Filters:High-Performance Mesh

Radiator Support

• Front:Up to 420 mm
• Top:Up to 360mm
• Rear:Up to 140mm

Fan Specs

• Model:F360 RGB Core Fan (Case Version)
• Speed:1,700 +/- 200 RPM
• Airflow:50.1 CFM
• Static:1.27 mm-H2O
• Noise:23.3 dBA
• Fan Connector:3-pin

Physical Specifications

• Item Dimension (L"xW"xH"): 26 x 13 x 23
• Weight: 56.00lbs

Inside the Box

• H7 Flow RGB: 1
• F360 RGB Core (pre-installed, case version): 1
• Installation Accessories
• Manual

Warranty Information: 2 Years from NZXT
