Supermicro CSE-510T-203B 1U mITX ATX Chassis 2x 2.5 SAS/SATA 200W Power Supply

Supermicro Case CSE-510T-203B 1U High-Efficiency Low Noise 2.5inch Drive Bay 200W Black

Key Features

• 200W High-efficiency Power Supply 80 PLUS, Gold Level Certified
• Low noise level
• 2x 2.5" hot-swap SAS/SATA HDD Bays
• 1x Low-profile PCI expansion slot
• 3x 8500 RPM Cooling Fan
• Power Switch, Reset Button & 5 LED Indicators
• Extra Compact Size

Technical Specifications

• Processor Support: Supports Single Intel / AMD Processor
• Expansion Slots: 1x low-profile PCI expansion slot (Optional) (Riser Card Required use the full-height I/O bracket on the low-profile add-on card to install)

Drive Bays

• Hotswap
• 2x 2.5" SAS / SATA Hot-swap drive trays
• SAS or enterprise SATA HDD only recommended

Front Panel Buttons:

• Power on/off Button
• System Reset Button

LEDs:

• Power LED
• Hard Drive Activity LED
• 2x Network Activity LEDs
• System Overheat LED

System Cooling

• FAN: 3 x 8500 RPM Cooling Fan

Operating Environment (System)

• Operating Temperature Range:: - 5C - 35C (41F - 95F)
• Non-Operating Temperature Range:: - -40 60C (-40 -140 F)
• Humidity Range:: - 8 90% Non-Condensing
• Non-Operating Humidity Range:: - 5 95% Non-Condensing

Power Supply

• 200W Low Noise AC-DC Power Supply with PFC
• AC Voltage: 100-240V, 50-60 Hz, 2.6 Amp
• Certifications: 80 PLUS GOLD Certified
• Power Supply Safety / EMC
  • USA - UL listed, FCC
  • Canada - CUL listed
  • CCC Certification
  • EN 60950/IEC 60950-Compliant
  • Europe/CE Mark
  • Germany - TUV Certified

Physical Specifications

• Form Factor: 11.3"-Depth Mini 1U chassis support for maximum motherboard size - 9.6" x 9.6"
• Colors: Black
• Item Dimension (L"xW"xH"): 17.2 x 11.3 x 1.7
• Weight: 12.5 lb

Warranty: 1 Year from Supermicro

All Supermicro products are shipped in Brown Boxes and are NOT in Retail packs. Manuals and Guides are available from the official Supermicro website.

This offer is for the Supermicro Chassis 510T-203B with Power Supply only.
