Supermicro CSE-733TQ-668B Mid-Tower ATX eATX mATX Front IO HDD USB 668W 80+ PSU

Key Features

• 4x 3.5" SAS/SATA Backplane for Hot-Swappable Drives (Support SGPIO)
• Front HDD Door Lock
• Front I/O Ports: 2x USB 2.0
• 1x 12cm Rear (4000 rpm) PWM Fan & 1x 9cm Front (4200 rpm) PWM Fan
• Mid-Tower Chassis Supports max. Motherboard, Sizes E-ATX 12" x 13"/ATX/Micro ATX
• 668W Platinum Level Certified High-Efficiency Power Supply
• 2x 5.25" External HDD Drive Bays & 4x 3.5" HDD Drive Bays

Specifications

Form Factor

• Mid-tower chassis - supports for maximum motherboard sizes: 12 inch x 13 inch E-ATX and ATX

Processor Support

• Dual and Single Intel and AMD processors

Color

• Black

Expansion Slots

• 7 full-height and full-length expansion slot(s)

Drive Bays

• 4 x 3.5 inch hot-swap SAS/SATA drive bay with SGPIO

Backplane

• 4x3.5 inch SAS2/SATA3 backplane w/SES-II

Peripheral Drives

• 2 x standard 5.25 inch drive bay
• 1 x 3.5 inch internal fixed drive bay

Front Panel

• Buttons
  • Power On/Off button
  • System Reset Button

LEDs

• 1 Network Activity LEDs
• HDD activity LED
• Power LED
• System Overheat LED

Ports

• 2x USB 2.0 Port(s)

Systems Cooling

• Fans
  • 1 x 12cm rear exhaust fan(s)
  • 1 x 9cm hot-swap cooling fan(s)

Operating Environment (System)

• Operating Temperature Range
  • 5oC - 35oC (41oF - 95oF)
• Non-Operating Temperature Range
  • -40oC - 70oC (-40oF - 158oF)
• Operating Relative Humidity Range
  • 8% - 90% (non-condensing)
• Non-Operating Relative Humidity Range
  • 5% - 95% (non-condensing)

Power Supply

• PS2 668W Multi-output power supply 80PLUS Platinum

Power Efficiency

• 92%

Total Output Power and Input

• 668W with Input 100 - 240Vac

AC Input Frequency

• 50-60Hz

Output Type

• 24pin ATX

Certification

• Platinum Certified
• Regulatory (Power Supply)
• Power Supply Safety / EMC
  • BSMI
  • CCC
  • CE/EMC
  • FCC class B
  • TUV/CB
  • UL/CUL

Item Dimension (L"xW"xH")

• 27 x 25 x 12

Weight

• 59.00 LB

Warranty Information

• 1 Year from Supermicro

All Supermicro products are shipped in Brown Boxes and are NOT in Retail packs. Manuals and Guides are available from the official Supermicro website.

This offer is for the Supermicro Mid Tower Case 733TQ-668B with Power Supply only.
