Supermicro CSE-825TQC-R1K03LPB 2U ATX eATX Chassis 10x 3.5 SAS/SATA 1000W PSU

Key Features

• SAS3(12 Gbps) HDD support
• 8x 3.5" Hot-swap SAS3/ SATA Drive Bays & 2x Fixed 3.5" Drive Bays
• 1000W Redundant Power Supplies Titanium Level (96%)
• Adjustable Air Shroud with Enhanced cooling design
• 7 Slots Low-profile PCI expansion
• Power button, Power switch and 6 LED Indicators

Compatible Motherboards and Servers

• X11DPi-N
• X11DPi-NT
• 6029P-TR
• 6029P-TRT

Specifications

Form Factor

• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards

Processor Support

• Dual and Single Intel and AMD processors

Color

• Black

Expansion Slots

• 7 low-profile expansion slot(s)

Drive Bays

• 8 x 3.5" hot-swap SAS/SATA drive bay with SGPIO
• 2 x 3.5" fixed drive bay

Backplane

• 8-port 2U SAS3 12Gbps TQ backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD

Peripheral Drives

• Optional 1 x slim DVD-ROM drive bay (Not included, sold separately)
• Optional 2 x USB 2.0 ports (Not included, sold separately)
• Optional 1 x COM port tray
• Optional 2 x USB 3.0 ports

Front Panel

• Buttons:
  • Power On/Off button
  • System Reset Button
• LEDs:
  • 2 Network Activity LEDs
  • HDD activity LED
  • Power Status LED
  • Power Fail LED
  • System Information LED

Systems Cooling

• Fans: 3 x 80mm heavy duty fan(s) with PWM fan(s) speed control

Operating Environment (System)

• Operating Temperature Range: 5oC - 35oC (41oF - 95oF)
• Non-Operating Temperature Range: -40oC - 70oC (-40oF - 158oF)
• Operating Relative Humidity Range: 8% - 90% (non-condensing)
• Non-Operating Relative Humidity Range: 5% - 95% (non-condensing)

Power Supply

• 1U 800/1000W Redundant Titanium Single Output Power Supply W/PMbus
• Power Efficiency: 96%
• Total Output Power and Input:
  • 800W with Input 100 - 127Vac
  • 1000W with Input 200 - 240Vac
  • 1000W with Input 200 - 240Vdc
• AC Input Frequency: 50-60Hz
• Dimensions (L x W x H): 336 x 76 x 40 mm
• Output Type: Backplanes (gold finger)
• +12V:
  • Max: 66.7A (100Vac - 127Vac)
  • Max: 83A (200Vac - 240Vac)
  • Max: 83A (200 - 240)
  • +5Vsb: Max: 4A / Min: 0A
• Power Distributor:
• PDB-PT825-8824
• O/P: 12V/75
• +5V Max: 30
• +3.3V Max: 24
• -12V Max: 0.6
• Certification: Titanium Certified
• Regulatory (Power Supply) Power Supply Safety / EMC:
• • BSMI
  • CCC
  • CE/EMC
  • FCC class A
  • UL/CB
  • UL/CUL

Weight: 55 lbs

Warranty Information: 1 Year from Supermicro

All Supermicro products are shipped in Brown Boxes and are NOT in Retail packs. Manuals and Guides are available from the official Supermicro website.

This offer is for the Supermicro Chassis 825TQC with Power Supply only.
