Supermicro CSE-825TQC-R802LPB Case 2U 800W 8x3.5"HS SAS3/SATA 2x3.5"fixed drive

Key Features

• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards
• 8 x 3.5" hot-swap SAS3/SATA drive bay, 2 x 3.5" fixed drive bay
• 8-port 2U SAS3 12Gbps TQ backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD
• 1U 800W Redundant Power Supply 76mm width, W/PMbus, Titanium
• 7 low-profile expansion slot(s)
• 3 x 80mm Hot-swap PWM Fans

SPECIFICATIONS

Product SKU

• SuperChassis 825TQC-R802LPB

Form Factor

• 2U chassis supports for maximum motherboard sizes - 13.68" x 13", E-ATX 12" x 13", ATX 12" x 10" motherboards

Processor Support

• Dual and Single Intel® and AMD processors

Dimensions

• Height: 3.5" (89 mm)
• Width: 17.2" (437 mm)
• Depth: 25.5" (647 mm)
• Gross Weight: 52 lbs (23.59 kg)
• Net Weight: 37 lbs (16.78 kg)
• Packaging (W x H x L): 26.7" (678 mm) x 11.4" (290 mm) x 34.5" (876 mm)
• Available Color: Black

Expansion Slots

• 7x Low-profile expansion slot(s)

Drive Bays

• 2x 3.5" fixed drive bay
• 8x 3.5" hot-swap SAS3/SATA drive bay

Backplane

• 8-Port 2U SAS3 12Gbps TQ backplane, support up to 8x 3.5-inch SAS3/SATA3 HDD/SSD

Peripheral Drives

• Optional 1x slim DVD-ROM drive bay
• Optional 1x COM port tray
• Optional 2x USB 2.0 ports
• Optional 2x USB 3.0 ports

Front Panel

• Button:
  • Power On/Off button
  • System Reset button
• LED:
  • Power status LED
  • HDD activity LED
  • System Information LED
  • Power Fail LED
  • 2 Network Activity LEDs

Systems Cooling

• Fans:
• 3x 80mm Hot-swap PWM Fans

System Monitoring

• Chassis intrusion switch

Operating Environment (System)

• Operating Temperature Range: 5°C - 35°C (41°F - 95°F)
• Non-Operating Temperature Range: -40°C - 70°C (-40°F - 158°F)
• Operating Relative Humidity Range: 8% - 90% (non-condensing)
• Non Operating Relative Humidity Range: 5% - 95% (non-condensing)

Power Supply

• 1U 800W Redundant Power Supply 76mm width, W/PMbus, Titanium
• Power Efficiency: 96%
• Total Output Power and Input:
  • 800W with Input 200 - 240Vdc
  • 800W with Input 100 - 240Vac
• AC Input Frequency: 50-60Hz
• Dimensions (L x W x H): 336 x 76 x 40 mm
• Output Type: Backplanes (gold finger)
• +12V:
  • Max: 66A / Min: 0A (100Vac - 240Vac)
  • Max: 66A / Min: 0A (200Vdc - 240Vdc)
• +5Vsb: Max: 4A / Min: 0A
• Power Distributor:
  • PDB-PT825-8824
  • O/P: 12V/75
  • +5V Max: 30A
  • +3.3V Max: 24A
  • -12V Max: 0.6A
• Certification: Titanium Certified  Titanium Certified

Power Supply Safety / EMC:

• BSMI
• CCC
• CE/EMC
• FCC class A
• TUV/CB
• UL/CUL
