Supermicro CSE-835TQC-R802B 3U ATX eATX Chassis 8x SAS/SATA 800W Titanium PSU

Key Features

• 800W Redundant High-efficiency Titanium Level Power Supplies
• 8x 3.5" Hot-swap SAS3/SATA3 drive bays, space to support 2x 5.25" Drive Bays & 1x Slim DVD
• Optional hot-swap Slim HDD/SSD drive Kit and Mobile Racks for additional storage
• 7x Full-height, Full-length Expansion Slots
• Five Fans (3 middle, 2 rear) & Adjustable Air Shroud for 100% Cooling Redundancy

Specifications

Form Factor

• 3U chassis support for motherboard size - E-ATX and ATX.
• Processor Support
• Dual and Single Intel and AMD processors

Color

• Black

Expansion Slots

• 7 full-height and full-length expansion slot(s)

Drive Bays

• 8 x 3.5" hot-swap SAS/SATA

Backplane

• 3U 8-Port Backplane Supports 8 x 3.5" SAS3/SATA3 HDD/SSD for X11 Platform

Peripheral Drives

• 1 x slim DVD-ROM drive bay

Front Panel

• Buttons
  • Power On/Off button
  • System Reset Button
• LEDs
  • 2 Network Activity LEDs
  • HDD activity LED
  • Power LED
  • Power Fail LED
  • System Overheat LED

Systems Cooling

• Fans
  • 3 x 80mm Hot-swap PWM Fans
  • 2 x 80mm rear hot-swap exhaust PWM fan(s)
• System Monitoring
  • Chassis intrusion switch

Operating Environment (System)

• Operating Temperature Range: 5oC - 35oC (41oF - 95oF)
• Non-Operating Temperature Range: -40oC - 70oC (-40oF - 158oF)
• Operating Relative Humidity Range: 8% - 90% (non-condensing)
• Non-Operating Relative Humidity Range: 5% - 95% (non-condensing)

Power Supply

• 1U 800W Redundant Power Supply 76mm width, W/PMbus, Titanium
• Power Efficiency: 96%
• Total Output Power and Input
  • 800W with Input 100 - 240Vac
  • 800W with Input 200 - 240Vdc
• AC Input Frequency: 50-60Hz
• Output Type: Backplanes (gold finger)
• +12V
  • Max: 66A (100Vac - 240Vac)
  • Max: 66A (200 - 240)
• +5Vsb: Max: 4A / Min: 0A
• Power Distributor
  • PDB-PT825-8824
  • O/P: 12V/75
  • +5V Max: 30
  • +3.3V Max: 24
  • -12V Max: 0.6

Certification

• Titanium Certified

Regulatory (Power Supply)

• Power Supply Safety / EMC
  • BSMI
  • CCC
  • CE/EMC
  • FCC class A
  • TUV/CB
  • UL/CUL

Item Dimension (L inchxW inchxH inch): 34 x 27 x 13

Weight: 86.00 LB

Warranty Information: 1 Year from Supermicro

All Supermicro products are shipped in Brown Boxes and are NOT in Retail packs. Manuals and Guides are available from the official Supermicro website.

This offer is for the Supermicro Chassis 835TQ with Power Supply only.
