APC SMTL1000RM2UCNC Smart-UPS, Line Interactive, 1000VA, Lithium-ion, Rack/Tower

General Information

• Manufacturer: Schneider Electric SA
• Brand Name: APC by Schneider Electric
• Manufacturer Part Number: SMTL1000RM2UCNC
• Product Name: Smart-UPS 1000VA Rack-mountable UPS
• Product Line: Smart-UPS
• Product Type: Line-interactive UPS

• 1000VA/800W line interactive pure sine wave 2U rackmount UPS
• Ideal for small edge environment, back office, network infrastructure and IDF/MDF closets
• Lithium-ion battery minimizes the need to replace battery during the lifetime of UPS
• Short depth UPS provides extra space for cable management
• Tower convertible with stabilizing feet (sold separately)
• Cloud-based remote power monitoring via SmartConnect Ethernet Port
• Preinstalled Network Management Card for network-based UPS monitoring & management
• Graceful shutdown of physical servers, virtual machines and HCI Clusters

Physical Characteristics

• Weight (Approximate): 35.94 lb
• Rack Height: 2U
• Height: 3.4"
• Width: 17.2"
• Depth: 12.5"
• Product Color: Black, Silver
• Color Family: Dual Color
• Mounting Preference Lower

Interfaces/Ports

• USB (HID Compliant) Port: Yes
• Environmental Conditions
• Thermal Dissipation: 3.81 W
• Storage Relative Humidity: 0% - 95%

Management

• Network Management: SmartConnect
• Alarm: Low Battery

Battery Information

• Battery Life: 10 Year
• DC System Voltage: 24 V DC
• Typical Battery Recharge Time: 3 Hour

Technical Information

• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15P
• Transfer Time: 6 ms
• Receptacle Detail: 6 x NEMA 5-15R

Power Description

• Surge Energy Rating: 680 J
• Waveform Type: Sine Wave
• Output Frequency: 60 Hz
• Input Frequency: 60 Hz
• Load Capacity (VA): 1000 VA
• Load Capacity (Watt): 800 W

Miscellaneous

• Package Contents
  • Smart-UPS 1000VA Rack-mountable UPS
  • Installation Guide
  • Rack Mounting Support Rails
  • USB Cable

Warranty

• Limited Warranty: 5 Year from APC
