APC SMX1000C Smart-UPS X, Line-interactive UPS - 1000VA, Rack/tower

General Information

• Manufacturer: Schneider Electric SA
• Brand Name: APC by Schneider Electric
• Manufacturer Part Number: SMX1000C
• Product Line: Smart-UPS
• Product Series: SMX
• Product Name: Smart-UPS SMX 1000VA Tower/Rack Convertible UPS
• Packaged Quantity: 1 Each
• Product Type: Line-interactive UPS

• Marketing Information: This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 1000VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA 5-15P input and 8x NEMA 5-15R outlets. The UPS offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The Smart-UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 2 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.

Technical Information

• AVR: Yes
• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15P
• Receptacle Detail: 8 x NEMA 5-15R
• Number of Battery & Surge Outlets: 8
• Cord Length: 8 ft
• Transfer Time: 0 ns
• Application/Usage:
  • Mission Critical Equipment
  • Server Room
  • Business
  • IT Infrastructure
  • Security System
  • Communication System
  • Electronic
  • VoIP
  • Telecommunication
  • Workstation
  • Network Device
  • POS Terminal
  • Edge Computing
  • Data Storage
  • Mobile Device
  • Tablet
  • Computer

Power Description

• Load Capacity (VA): 1000 VA
• Load Capacity (Watt): 900 W
• Input Voltage: 120 V
• Input Voltage Range: 82 V AC - 144 V AC
• Output Voltage: 120 V AC
• Input Frequency: 63 Hz
• Waveform Type: Sine Wave
• Surge Energy Rating: 600 J

Management

Network Management: SmartConnect

Alarm:

• On Battery
• Low Battery
• Overload

Controls/Indicators

• Status Indicators:
• Control Panel: Multi-function LCD Status
• Control Console
• Interfaces/Ports
• Serial Port: Yes
• Network (RJ-45): Yes
• EPO Port: Yes
• USB (HID Compliant) Port: Yes

Battery Information

• Number of Batteries: 1
• Battery Chemistry: Lead Acid
• Backup/Run Time (Full Load): 8 Minute
• Backup/Run Time (Half Load): 14.80 Minute
• Typical Battery Recharge Time: 3 Hour
• Replaceable Battery: Yes

Physical Characteristics

• Color Family: Black
• Product Color: Black
• Height: 17"
• Width: 3.5"
• Depth: 19.3"
• Rack Height: 2U
• Form Factor: Rack-mountable
• Mounting Preference: Lower
• Weight (Approximate): 50.40 lb

Miscellaneous

For Country/Region: United States

Package Contents:

• Smart-UPS SMX 1000VA Tower/Rack Convertible UPS
• Cat 5 Ethernet cable
• Installation guide
• Rack mounting brackets
• Removable support feet
• Smart UPS signalling RS-232 cable
• USB cable

Warranty

• Limited Warranty: 3 Year from APC
