APC SMX1500RM2UC Smart UPS X 2U Rack Smart Connect 8x Outlets 1440VA 1350W 645J

MARKETING INFORMATION:

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 1440VA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with NEMA 5-15P input and 8x NEMA 5-15R outlets. The UPS offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The Smart-UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.

GENERAL INFORMATION

• Manufacturer: Schneider Electric SA
• Manufacturer Part Number: SMX1500RM2UC
• Brand Name: APC by Schneider Electric
• Product Line: Smart-UPS
• Product Series: SMX
• Product Name: Smart-UPS SMX 1500VA Tower/Rack Convertible UPS
• Packaged Quantity: 1 Each
• Product Type: Line-interactive UPS

TECHNICAL INFORMATION

• AVR: Yes
• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15P
• Receptacle Detail: 8 x NEMA 5-15R
• Number of Battery & Surge Outlets: 8
• Cord Length: 8 ft
• Transfer Time: 0 ns

APPLICATION/USAGE:

• Mission Critical Equipment
• Server Room
• Business
• IT Infrastructure
• Security System
• Communication System
• Electronic
• VoIP
• Telecommunication
• Workstation
• Network Device
• POS Terminal
• Edge Computing
• Data Storage
• Mobile Device
• Tablet
• Computer

POWER DESCRIPTION

• Load Capacity (VA): 1440 VA
• Load Capacity (Watt): 1350 W
• Input Voltage: 120 V
• Input Voltage Range: 82 V AC - 144 V AC
• Output Voltage: 120 V AC
• Input Frequency: 63 Hz
• Waveform Type: Sine Wave
• Surge Energy Rating: 645 J

MANAGEMENT

• Network Management: SmartConnect
• Alarm:
  • On Battery
  • Low Battery
  • Overload
• Status Indicators/Control Panel:
  • Multi-function LCD Status
  • Control Console

INTERFACES/PORTS

• Serial Port: Yes
• Network (RJ-45): Yes
• EPO Port: Yes
• USB (HID Compliant) Port: Yes

BATTERY INFORMATION

• Number of Batteries: 1
• Battery Chemistry: Lead Acid
• Backup/Run Time (Full Load): 5 Minute
• Backup/Run Time (Half Load): 14.80 Minute
• Typical Battery Recharge Time: 3 Hour

PHYSICAL CHARACTERISTICS

• Color Family: Black
• Product Color: Black
• Height: 3.5"
• Width: 17"
• Depth: 19.3"
• Rack Height: 2U
• Form Factor: Rack-mountable
• Mounting Preference: Lower
• Mounting Location: Front
• Weight (Approximate): 54.72 lb

PACKAGE CONTENTS:

• Smart-UPS SMX 1500VA Tower/Rack Convertible UPS
• Cat 5 Ethernet cable
• Installation guide
• Rack mounting hardware
• Rack mounting support rails
• Removable support feet
• Smart UPS signalling RS-232 cable
• USB cable

CERTIFICATIONS & STANDARDS:

• cUL Listed|ENERGY STAR V2.0 (USA)
• Software Included: Powerchute Serial Edition
• Energy Star: Yes
• Product Take Back Program: No
• Mercury Free: Yes

Limited Warranty: 3 Year direct from APC
