APC SMX3000RMHV2U Smart-UPS X, Line Interactive, 3kVA, Rack/tower convertible 2U

Overview

This APC Smart-UPS is designed for IT managers or network administrators to maintain business uptime, data transfer and continuity during prolonged power outages. The 3kVA line interactive 2U rack/tower UPS provides pure sine wave power to support critical electronics during power disruptions. The SMX comes with IEC 320 C20 input (includes BS1363A, IEC 320 C20 and Schuko CEE 7/EU1-16P power cords), 8x IEC 320 C13 and 1x IEC 320 C19 outlets. The UPS has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. This uninterrupted power supply can connect to EcoStruxure IT or third-party centralized management platforms. The SMX UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. This is compatible with dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. The Smart-UPS comes with a pair of tower-mounting stabilizing feet and rack-mounting brackets. The 3 switchable outlet groups allow more granular management of the power supplied to your devices. The Emergency Power Off feature enables the UPS to remotely shutdown during emergencies.

• Schneider Electric line interactive Smart UPS
• Uninterruptible Power Supply
• SMX UPS
• Battery backup
• Switchable outlet group UPS

General Information

• Manufacturer: Schneider Electric SA
• Brand Name: APC by Schneider Electric
• Manufacturer Part Number: SMX3000RMHV2U
• Product Model: SMX3000RMHV2U
• Product Name: Smart-UPS 3000 VA Tower/Rack Mountable UPS
• Product Line: Smart-UPS
• Product Series: SMX
• Product Type: Line-interactive UPS

Physical Characteristics

• Weight (Approximate): 82.28 lb
• Rack Height: 2U
• Height: 3.3"
• Width: 17"
• Depth: 26.3"
• Product Color: Black
• Mounting Location: Front
• Mounting Preference: Lower

Technical Information

• Emergency Power OFF: Yes
• Plug/Connector Type British BS1363A
• IEC 320-C20
• Receptacle Type Schuko CEE 7/EU1-16P
• Number of Battery & Surge Outlets 11
• Transfer Time 4 ms
• Receptacle Detail
  • 8 x IEC 320-C13
  • 2 x IEC Jumper
  • 1 x IEC 320-C19

Interfaces/Ports

• USB: Yes
• Serial Port: Yes
• Total Number of Expansion Slots: 1

Power Description

• Surge Energy Rating: 645 J
• Waveform Type: Sine Wave
• Load Capacity (VA): 3000 VA
• Load Capacity (Watt): 2700 W

Battery Information

• Hot Swappable: Yes
• Backup/Run Time (Half Load): 18 Minute
• Backup/Run Time (Full Load): 6 Minute
• Battery Characteristics Maintenance-free, Sealed, Spill-proof
• Typical Battery Recharge Time: 3 Hour

Miscellaneous

Package Contents

• Smart-UPS 3000 VA Tower/Rack Mountable UPS
• CD with software
• Documentation CD
• Rack mounting brackets
• Smart UPS signalling RS-232 cable
• USB cable
• User manual

Limited Warranty 3 Year from APC
