CyberPower CP685AVRG 4+4 Outlets Compact AVR UPS 685VA 390W for Small Equipments

General Information

• Manufacturer: CyberPower Systems, Inc
• Manufacturer Part Number: CP685AVRG
• Brand Name: CyberPower
• Product Series: AVR UPS
• Product Model: CP685AVRG
• Product Name: CP685AVRG AVR UPS Series
• Product Type: Line-interactive UPS

Marketing Information

The CyberPower CP685AVRG uninterruptible power supply (UPS) system provides battery backup and surge protection for lightning-induced surges and other power events that can damage electronic equipment. This UPS, with line-interactive topology, uses simulated sine wave output to deliver enough battery backup to power connected electronics through a utility power failure. The unit has enough runtime to perform a graceful shutdown to protect against the loss of data and damage to valuable desktop computers, workstations, networking devices, and home entertainment systems.

The CP685AVRG uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power. AVR is essential in areas where power fluctuations occur frequently, and it helps to extend the unit's battery life. CyberPower designed the CP685AVRG to minimize noise for a quieter work environment and run efficiently to reduce power consumption.

• Experience higher efficiency with lower energy cost
• 685 VA load capacity - work without any interruption during power outages
• Prevent critical data loss by staying powered during a blackout with up to 390 W load capacity
• Up to 2 minute runtime on full load to preserve critical data from power shortage interruptions

Technical Information

• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15R
• Receptacle Detail: 8 x NEMA 5-15R
• Transfer Time: 4 ms
  • Application/Usage:
  • Desktop Computer
  • Network Device
  • Home Theater
  • Router
  • Modem
  • VoIP Phone System
  • Workstation

Power Description

• Load Capacity (VA): 685 VA
• Load Capacity (Watt): 390 W
• Input Voltage: 120 V AC
• Input Voltage Range: 90 V AC - 140 V AC
• Output Voltage: 120 V AC
• Waveform Type: Simulated Sine Wave

Interfaces/Ports

• Network (RJ-45): Yes

Battery Information

• Backup/Run Time (Full Load): 2 Minute
• Typical Battery Recharge Time: 8 Hour

Physical Characteristics

• Height: 6.8"
• Width: 11"
• Depth: 3.5"
• Form Factor: Compact
• Weight (Approximate): 12 lb

Package Contents:

• CP685AVRG AVR UPS Series
• User's Manual
• USB Device Cable
• PowerPanel Personal Software CD or Free Download Card

Energy Star: Yes

Country of Origin: China

Environmentally Friendly: Yes

Limited Warranty: 3 Year from CyberPower
