Eaton 5SC500 5SC UPS 500VA 350 Watt 120V Line-Interactive - 120 V AC Input

General Information

• Manufacturer: Eaton Corporation
• Brand Name: Eaton
• Manufacturer Part Number: 5SC500
• Product Series: 5SC
• Product Name: 5SC UPS

Marketing Information:

The flexible Eaton 5SC UPS delivers affordable and reliable protection for small business servers, storage and network equipment. The LCD interface provides clear status of UPS key parameters and allows configuration for output voltage, audible alarm and power input sensitivity. By using Eaton's Intelligent Power Manager software with the 5SC UPS you get up-to-the-minute information on the status of power in your network. The 5SC offers pure sinewave output for sensitive equipment as well as buck and boost operation to correct a wide range of input voltage variations without using batteries.

Product Type: Line-interactive UPS

Technical Information

• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15R
• Receptacle Detail: 4 x NEMA 5-15R
• Protection Type: Surge
• Cord Length: 5.91 ft

Power Description

• Load Capacity (VA): 500 VA
• Load Capacity (Watt): 350 W
• Input Voltage: 120 V AC
• Output Voltage: 120 V AC

Management

• Battery Management: ABM Technology

Interfaces/Ports

• Serial Port: Yes
• Network (RJ-45): Yes
• USB: Yes

Battery Information

• Battery Characteristics: Maintenance-free, Sealed
• Battery Chemistry: Lead Acid
• Hot Swappable: No

Environmental Conditions

• Maximum Operating Temperature:
• 95°F (35°C)
• Sound Emission: 55 dB

Physical Characteristics

• Color Family: Black
• Product Color: Black
• Height: 8.2"
• Width: 5.9"
• Depth: 9.4"
• Form Factor: Tower

Miscellaneous

• Package Contents:
  • 5SC UPS
  • User Manual CD
  • Intelligent Power Manager Software CD
  • USB Cable
  • Serial Cable (RJ45 to DB9)
  • Safety Instructions
  • Limited Warranty Details
• Certifications & Standards:
  • CE
  • cULus
  • NOM
  • IEC 62040-2:2006 Cat C2
  • CISPR22 Class A
  • FCC part 15 Class A
• Software Included: Eaton Intelligent Power Software
• Country of Origin: Philippines
• Environmentally Friendly: Yes
• Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Warranty

• Limited Warranty: 2 Year from EATON
