Eaton AVR900U 12-Outlet UPS AVR USB Desk Wall 480W 120V 5x Battery Power 900VA

GENERAL INFORMATION

• Manufacturer: Eaton Corporation
• Manufacturer Part Number: AVR900U
• Brand Name: Tripp Lite by Eaton
• Product Series: AVR
• Product Name: AVR 900VA Desktop UPS
• Packaged Quantity: 1 Each
• Product Type: Line-interactive UPS

MARKETING INFORMATION:

AVR Series Line-Interactive UPS System offers ultra-compact, line-interactive protection for PCs and workstations. System maintains 120 volt nominal output over an input range of 83 to 147 volts. Workstation-optimized features include USB port (HID-PDC compliant), single-line telephone/DSL surge suppression, space saving right-angle input plug, six battery/surge-protected outlets and six additional surge-only outlets (12 total). USB port (included cable) works with free unattended shutdown software. Housing is mountable.

TECHNICAL INFORMATION

• AVR: Yes
• AVR Range: Boost +18% / Buck -15%
• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15R
• Receptacle Detail: 12 x NEMA 5-15R
• Number of Battery & Surge Outlets: 6
• Number of Surge-only Outlets: 6
• Transfer Time: 6 ms
• EMI/RFI Noise Filter: Yes
• Phase: Single Phase

POWER DESCRIPTION

• Load Capacity (VA): 900 VA
• Load Capacity (Watt): 480 W
• Input Voltage: 120 V AC
• Output Voltage:
  • 110 V AC
  • 115 V AC
  • 120 V AC
• Input Frequency: 60 Hz
• Output Frequency: 60 Hz
• Waveform Type: Pulse-width Modulated Sine Wave
• Surge Energy Rating: 316 J

MANAGEMENT ALARM:

• Battery Backup
• Low Battery
• Fault
• Overload
• Replace Battery
• Controls/Indicators: 2 Status LEDs; GREEN indicates power status and operating mode / RED indicates battery-low, overload, replace-battery and fault conditions

INTERFACES/PORTS

• USB: Yes
• USB (HID Compliant) Port: Yes
• BATTERY INFORMATION
• DC System Voltage: 12 V DC
• Battery Chemistry: Lead Acid
• Backup/Run Time (Full Load): 2.70 Minute
• Backup/Run Time (Half Load): 10 Minute
• Typical Battery Recharge Time: 8 Hour
• Replaceable Battery: Yes

ENVIRONMENTAL CONDITIONS

• Maximum Operating Temperature: 104°F (40°C)
• Storage Temperature: 5°F (-15°C) - 113°F (45°C)

PHYSICAL CHARACTERISTICS

• Height: 4.1"
• Width: 7.5"
• Depth: 12"
• Form Factor: Ultra-compact Desktop/Tower/Wall Mount
• Weight (Approximate): 16.50 lb

PACKAGE CONTENTS:

• AVR 900VA Desktop UPS
• Owner's manual

CERTIFICATIONS & STANDARDS:

• Tested to UL1778 (USA)
• cUL1778 (Canada)
• NOM (Mexico)
• FCC Class B (Emissions)
• FCC Part 68
• Industry Canada (Telecommunications)

Limited Warranty: 3 Years from EATON
