Eaton INTERNET600U 10-Outlet UPS AVR USB 325W 120V 5x Battery Power 600VA Black

GENERAL INFORMATION

• Manufacturer: Eaton Corporation
• Manufacturer Part Number: INTERNET600U
• Brand Name: Tripp Lite
• Product Line: Internet Office
• Product Model: INTERNET600U
• Product Name: Internet Office INTERNET600U 600VA Ultra-compact desktop/tower/wall mount UPS
• Product Type: Standby UPS

MARKETING INFORMATION:

600VA/325W/120V Battery Backup for PCs, Home Theater and Digital Signage
The standby INTERNET600U UPS system provides reliable battery backup and AC power protection against blackouts, brownouts, overvoltages, surges and line noise that can damage valuable electronics or destroy data. The 10-outlet 120V battery backup is ideal protection for your home office, media center or commerce components, including computers, routers, printers, NAS drives, HDTVs, Blu-ray players, game consoles, media players, DVRs and audio receivers.

TECHNICAL INFORMATION

• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15R
• Receptacle Detail: 10 x NEMA 5-15R
• Number of Surge-only Outlets: 5
• Dataline Protection: RJ-11/RJ-45
• Overload Protection: Yes
• Cord Length: 5 ft
• Transfer Time: 10 ms
• EMI/RFI Noise Filter: Yes
• Phase: Single Phase
• Surge Sppression: Yes

FEATURES:

• Audible Alarm
• Cold Start Function
• Green Energy Saving

POWER DESCRIPTION

• Load Capacity (VA): 600 VA
• Load Capacity (Watt): 325 W
• Input Voltage: 120 V AC
• Input Current: 6 A
• Output Voltage:
  • 120 V AC
  • 110 V AC
  • 115 V AC
• Input Frequency: 60 Hz
• Output Frequency:
  • 50 Hz
  • 60 Hz
• Waveform Type: Pulse-width Modulated Sine Wave
• Surge Energy Rating: 316 J
• Circuit Breaker: Yes
• Display: LCD

MANAGEMENT ALARM:

• Low Battery
• Fault
• Overload
• Replace Battery
• Controls/Indicators
• LED Status Indicators:
  • Operating Mode
  • Fault Status

INTERFACES/PORTS

• Network (RJ-45): Yes
• USB: Yes
• USB (HID Compliant) Port: Yes

BATTERY INFORMATION

• DC System Voltage: 12 V DC
• Battery Characteristics: Valve-regulated
• Battery Chemistry: Lead Acid
• Backup/Run Time (Full Load): 1 Minute
• Backup/Run Time (Half Load): 4.50 Minute
• Typical Battery Recharge Time: 6.50 Hour
• Replaceable Battery: Yes

ENVIRONMENTAL CONDITIONS

• Minimum Operating Temperature: 32°F (0°C)
• Maximum Operating Temperature: 104°F (40°C)
• Storage Temperature: 5°F (-15°C) - 113°F (45°C)
• Maximum Operating Elevation: 9842.52 ft
• Thermal Dissipation: 3.84 W

PHYSICAL CHARACTERISTICS

• Height: 4.1"
• Width: 4.3"
• Depth: 7.3"
• Form Factor: Ultra-compact Desktop/Tower/Wall Mount
• Weight (Approximate): 3.96 lb

PACKAGE CONTENTS:

• Internet Office INTERNET600U 600VA Ultra-compact desktop/tower/wall mount UPS
• USB Cable
• Owner's Manual

CERTIFICATIONS & STANDARDS:

• RETIE
• CSA
• NOM
• UL 1778
• FCC Part 15 Class B

OTHER INFORMATION

• UL Listed Certification
• Environmentally Friendly: Yes
• Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
• Limited Warranty: 3 Year from EATON
