Vertiv Liebert PSI5-1000RM1201U UPS 1000VA 900W 120V Line 1U Rack AVR 5 Outlets

General Information

• Manufacturer: Vertiv
• Manufacturer Part Number: PSI5-1000RM1201U
• Brand Name: Liebert
• Product Series: PSI5
• Product Model: PSI
• Product Name: PSI5-1000RM1201U UPS
• Product Type: Line-interactive UPS

Marketing Information:

The Vertiv Liebert PSI5 1kVA UPS is designed to protect and extend the life of your electronic devices in school, home and office. This 1U rack mount UPS offers cost-effective protection from downtime and damage caused by power outages, brownouts, sags, surges or noise interference. Automatic Voltage Regulation (AVR) extends battery life and safeguards critical equipment. Voltage regulation is from 83 to 159 VAC without using the battery. With advanced pure sine wave output, this line interactive UPS ensures availability of critical IT applications like network closets and small data centers. This battery backup allows orderly shutdown of critical equipment. It takes less than 6 milliseconds transfer time to battery. Add an optional Vertiv Liebert Unity communication card and remotely monitor up to 50 UPS systems through the free Vertiv Trellis Power Insight Application. It has a 2-year Vertiv UPS warranty with optional extensions for up to 5 years total coverage.

Technical Information

• AVR: Yes
• Plug/Connector Type: NEMA 5-15P
• Receptacle Type: NEMA 5-15R
• Receptacle Detail: 5 x NEMA 5-15R
• Transfer Time: 4 ms
• Phase: Single Phase
• Application/Usage:
  • Electronic Device
  • Education
  • Home
  • Office
  • Mission Critical Equipment
  • Data Center
  • Network Closet

Power Description

• Load Capacity (VA): 1000 VA
• Load Capacity (Watt): 900 W
• Input Voltage: 120 V AC
• Input Voltage Range: 75 V AC - 146 V AC
• Output Voltage:
  • 100 V AC
  • 110 V AC
  • 115 V AC
  • 120 V AC
  • 125 V AC
• Input Frequency: 65 Hz
• Output Frequency: 60 Hz
• Waveform Type: Pure Sine Wave

Interfaces/Ports

• Serial Port: No
• Network (RJ-45): No
• EPO Port: Yes
• USB (HID Compliant) Port: Yes

Battery Information

DC System Voltage: 6 V DC

• Number of Batteries: 4
• Battery Characteristics: Valve-regulated, Non-spillable
• Battery Chemistry: Lead Acid
• Battery Size: 6V
• Battery Capacity: 9000 mAh
• Backup/Run Time (Full Load): 5 Minute
• Backup/Run Time (Half Load): 13 Minute
• Typical Battery Recharge Time: 6 Hour
• Hot Swappable: Yes

Environmental Conditions

• Maximum Operating Temperature: 104°F (40°C)
• Storage Temperature: 5°F (-15°C) - 122°F (50°C)
• Maximum Operating Elevation: 9842.52 ft
• Operating Humidity: 20% - 90%
• Storage Relative Humidity: 20% - 90%

Physical Characteristics

• Height: 1.7"
• Width: 17.2"
• Depth: 17.7"
• Rack Height: 1U
• Form Factor: Rack-mountable
• Weight (Approximate): 36.40 lb

Package Contents:

• PSI5-1000RM1201U UPS
• Rack Mount Ears
• USB Cable
• Safety Manual
• Quick Installation Guide
• Software Included:
• Power Insight 2.2

Energy Star: No

Country of Origin: China

TAA Compliant: No

Environmentally Friendly: Yes

Limited Warranty: 2 Years rom Vertiv
