StarTech PEXUSB312A3 2 Port USB 3.2 Gen 2 10G PCIe Controller Exp Card Low Prof
Regular price
$54.38 USD
Sale price
$54.38 USD
Regular price
$51.24 USD
Description
Couldn't load pickup availability
StarTech PEXUSB312A3 2 Port USB 3.2 Gen 2 10G PCIe Controller Exp Card Low Prof
Current product
Current
Vendor:
citiCALLS
StarTech PEXUSB312A3 2 Port USB 3.2 Gen 2 10G PCIe Controller Exp Card Low Prof
Regular price
$54.38 USD
Sale price
$54.38 USD
Regular price
$51.24 USD
Options
Descriptions
2-Port USB PCIe Card with 10Gbps/port - USB 3.2 Gen 2 Type-A PCI Express 3.0 x2 Host Controller Expansion Card - Add-On Adapter Card - Full/Low Profile - Windows & Linux
USB 3.2 Gen 2 (10 Gbps) | PCI-Express 3.0 | PCIe x2 Slot | USB Type-A
Product ID: PEXUSB312A3
..
Warranty Information
Warranty
Lifetime
Connector(s)
Connector Type(s)
1 - PCI Express x4
Internal Ports
1 - SATA Power (15 pin)
External Ports
2 - USB 3.2 Type-A (9 pin, Gen 2, 10Gbps)
Environmental
Operating Temperature
5°C to 50°C (41°F to 122°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Humidity
20%~80% RH
Hardware
Ports
2
Interface
PCI Express x4
Bus Type
USB 3.2 Gen 2 10Gbps
Card Type
Standard Profile (LP bracket incl.)
Port Style
Integrated on Card
Industry Standards
USB 3.2 Specification
PCI Express Base Specification Rev. 3.0
Intel xHCI Specification Rev. 1.1
UASP (USB Attached SCSI Protocol) Rev. 1.0
Chipset ID
ASMedia - ASM3142
Packaging Information
Package Height
1.4 in [3.6 cm]
Package Length
8.2 in [20.8 cm]
Shipping (Package) Weight
4.7 oz [132.0 g]
Package Width
5.8 in [14.8 cm]
Package Quantity
1
Performance
Total USB Power Output
4.5W (5V @ 0.9A) nominal, per port - Current draw above 2.0A (10W) will initiate Over-Current Protection
Maximum Data Transfer Rate
10Gbps
Type and Rate
USB 3.2 Gen 2 - 10 Gbit/s
UASP Support
Yes
Physical Characteristics
Color
Black
Product Height
0.7 in [1.9 cm]
Product Length
3.9 in [10.0 cm]
Weight of Product
2.3 oz [65.0 g]
Product Width
4.7 in [12.0 cm]
Software
OS Compatibility
Windows® 7, 8, 8.1, 10, 11
Windows Server® 2012 R2, 2016, 2019, 2022
macOS 10.13 to 10.15, 11.0, 12.0, 13.0, 14.0
Linux® 3.5 and up - LTS Versions only
Windows Server® 2012 R2, 2016, 2019, 2022
macOS 10.13 to 10.15, 11.0, 12.0, 13.0, 14.0
Linux® 3.5 and up - LTS Versions only
Special Notes / Requirements
System and Cable Requirements
PCI Express enabled computer or server with a PCI Express x4 slot or higher (x8, x16)
Optional SATA power connector
The maximum throughput of this card is limited by the bus interface. PCI Express Gen 1.0 max throughput is 2.5Gbps. PCI Express Gen 2.0 and Gen 3.0 max throughput is 10Gbps
What's in the Box
Included in Package
1 - USB 3.1 Card
1 - Full-Profile Bracket (Pre-Installed)
1 - Low-Profile Bracket
1 - Quick Start Guide
