Adaptec 12008EXS Controller Card -HBA Adapter 8PT 24Gbps SAS SATA NVMe PCIe Gen4

Marketing Information

• Adaptec® HBA 1200 Series: 32i/16i/16e/8i/8e
• Tri-Mode SAS/SATA/NVMe™ Host Bus Adapters
• Host: x8/x16 PCIe® Gen 4
• Media: 24G SAS, 6G SATA, PCIe Gen 4 NVMe
• Maximum Performance and Security With Tri-Mode Functionality
• The Adaptec® HBA 1200 family is the industry's most versatile, fully featured and secure Tri-mode SAS/SATA/NVMe host bus adapter enabling high-performance connectivity solutions for server OEM, storage systems, data center and enterprise customers.
• The HBA 1200 series of PCIe Gen 4 to Tri-mode host bus adapters come in a wide range of performance optimized configurations optimized for the lowest possible cost. Built on Microchip's proven 5th generation storage controller, the SmartIOC 2200, the HBA 1200 product supports both x8 and x16 PCIe Gen 4 host interface adapters with 32, 16, and 8 media facing port variants for both internal and external Tri-mode connectivity. The HBA 1200 Ultra products are specifically designed for the most demanding NVMe and multi-port SAS SSD applications. The SmartIOC 2200 integrated PCIe Switch enables DirectPath technology - the industry's lowest latency and high bandwidth NVMe solution and the flexibility to support x1, x2, x4 and x8 wide NVMe SSDs.
• This industry first 24G SAS adapter supports SAS-4 connectivity as well as Microchip's Dynamic Channel Multiplexing (DCM) technology that aggregates expander attached SAS or SATA hard drives onto 24G SAS infrastructure with near 100% link efficiency for unparalleled throughput. Native HBA modes for all media types are also supported, which offers the lowest latency for memory-based PCIe storage. Superior performance enables the HBA 1200 Ultra to reach up to 29.6 GB/s throughput and 3.5M+ IOPs 4K random reads.
• Microchip’s Trusted Platform support delivers a new level of compute and supply chain security based on a hardware root of trust that is aligned with the Open Compute Security Project.

Key Software Features

• Adapter dynamic power management to save up to 30% power
• Support for up to 256 SAS/SATA target devices (238 SSDs/HDDs maximum-remainder are reserved for expanders and enclosure management)
• Support for NVMe target devices with Gen 3/4 interfaces (x1, x2, x4, and x8 wide interfaces)
• SAS expander support
• PCIe switch support
• SATA NCQ
• Multi-initiator (host)/clustering for SAS
• Hot-plug drive support
• Automatic/manual rebuild of hot spares
• SGPIO, SES, UBM and VPP enclosure management support
• PBSI, MCTP and Platform Level Data Model (PLDM) and Redfish Device Enablement (RDE) for out-of-band (BMC) management
• S.M.A.R.T. support
• Staggered drive spin-up
• Secure boot, secure update and attestation support
• USB image available on www.adaptec.com/en-us/support/start to boot the maxView GUI from any USB device for enhanced GUI-based setup and offline maintenance
