Eaton PDUMH20ATNET 16-Outlets 1U Power Distribution Unit PDU Rack 1.9kW 2 CORDS

GENERAL INFORMATION

• Manufacturer: Eaton Corporation
• Manufacturer Part Number: PDUMH20ATNET
• Brand Name: Tripp Lite by Eaton
• Product Model: PDUMH20ATNET
• Product Name: PDUMH20ATNET PDU Switched ATS 120V 20A 16 Outlet
• Product Type: PDU

TECHNICAL INFORMATION

• PDU Type: Switched
• Plug/Connector Type: NEMA L5-20P
• Plug/Connector Detail: 2 x NEMA L5-20P
• Receptacle Type: NEMA 5-15/20R
• Receptacle Detail: 16 x NEMA 5-15/20R

POWER DESCRIPTION

• Input Voltage: 120 V AC
• Output Voltage: 120 V AC
• Power Rating (VA): 2400 VA

MANAGEMENT

• Integrated Automatic Transfer Switch (ATS) allows PDU to operate from secondary input source when primary input fails
• Sequential outlet power-on prevents inrush-related equipment interaction on startup
• Programmable or real-time monitoring and outlet power control via secure web/network interface

PHYSICAL CHARACTERISTICS

• Color Family: Black
• Product Color: Black
• Mount Type: Rack-mountable
• Rack Height: 1U
• Number of Cord/Cable: 2
• Height: 1.8"
• Width: 1.8"
• Depth: 14.5"
• Weight (Approximate): 12.20 lb

PACKAGE CONTENTS:

• PDUMH20ATNET PDU Switched ATS 120V 20A 16 Outlet
• PDU with attached L5-20P input power cord
• Detachable C19 to NEMA L5-20P 12 ft/3.6m power cord for optional secondary input
• Two NEMA L5-20R to NEMA 5-20P plug adapters
• User manual with warranty information

OTHER INFORMATION

• TAA Compliant: Yes
• Environmentally Friendly: Yes
• Environmental Compliance: Restriction of Hazardous Substances (RoHS)
• Certifications & Standards:
  • 60950
  • Class A
  • TAA Compliant
• Limited Warranty: 2 Year from EATON
