Bosch NDS-5704-F360LE FLEXIDOME 5100i 12MP Indoor/Outdoor 360� Panoramic IR WDR

• Network camera - Helps achieve high-quality video results
• Up to 1920 x 1080 video resolution
• CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
• 1.26 mm maximum focal length for dependable identification distances with better coverage
• f/2.0 maximum aperture for better light absorption and dependable, better-quality results
• Up to 65.62 ft of night vision
• Full HD recording format for a lively video quality experience with maximum dependability
• Infrared night vision type consumes very little electrical power and provides evidentiary quality night-time surveillance video
• Fixed lens type is set all the way open to its lowest F stop, and is common on small form factor cameras
• Enjoy HD quality videos on your HDTV with the HDMI port facility

General Information

• Brand Name: Bosch
• Manufacturer: The Bosch Group
• Manufacturer Part Number: NDS-5704-F360LE
• Product Line: Flexidome
• Product Model: NDS-5704-F360LE
• Product Name: FLEXIDOME Panoramic 5100i IR
• Product Series: 5100i
• Product Type: Network Camera
• Weight (Approximate) (g): 820

Technical Information

• Connectivity Technology: Wired
• Effective Camera Resolution: 12MP
• Field of View: 182° (H) x 182° (V)
• HD Recording: Yes
• Lens Mount Type: Board Mount
• Lens Type: Fixed
• Maximum Aperture: f/2.0
• Maximum Focal Length (mm): 1.26
• Maximum Frame Rate: 30 fps
• Night Vision: Yes
• Night Vision Type: Infrared

Camera

• Night Vision Distance: 65.62 ft
• Night Vision Distance (mm): 20000
• Wide Dynamic Range: Yes

Display & Graphics

• Color Supported: Color, Monochrome
• Effective Camera Resolution (Pixel): 12000000
• Maximum Video Resolution: 1920 x 1080

Environmental Conditions

• Maximum Operating Temperature: 122°F (50°C)
• Maximum Operating Temperature (°F): 122
• Minimum Operating Temperature: -40°F (-40°C)
• Minimum Operating Temperature (°F): -40
• Operating Humidity: 100%

Exposure

• Longest Shutter Speed: 1/25 Second
• Shortest Shutter Speed: 1/500 Second

Interfaces/Ports

• HDMI: YES
• Network (RJ-45): Yes

Lens

• Focal Length: 1.26 mm
• Lens Included: Yes
• Maximum Focal Length: 1.26 mm

Network & Communication

• Remote Management: Yes

Physical Characteristics

• Color: White
• Diameter (mm): 148
• Durability
• Dust Resistant, Impact Resistant, Rain Resistant, Scratch Resistant, UV Resistant, Vandal resistant, Water Proof, Weather Resistant
• Form Factor: Dome
• Height: 2.8"
• Height (mm): 70
• Weight (Approximate): 1.81 lb

Power Description

• Input Voltage: 12V DC, 24V AC
• Input Voltage (V AC): 24
• Input Voltage (V DC): 12

Product Information

• Diameter: 5.8"
• Mount Type: Conduit Mount, Gang box Mount, Junction Box Mount, Surface mount

Storage

• Recording Formats: Full HD
• Storage Type: Memory Card

Video

• Maximum Frame Rate (fps): 30

Miscellaneous

• Miscellaneous
• Environmental Certification: China RoHS, EU RoHS, EU WEEE
• Environmentally Friendly: Yes
• Features: Built-in Microphone, Cross Line Detection, ePTZ, Noise Detection, Noise Reduction, Privacy Masking, Region of Interest, SD Card Local Storage, White Balance, Wide Dynamic Range
• Impact Protection Rating: IK10
• Indoor/Outdoor
• Indoor/Outdoor
• Ingress Protection Rating
• IP66
• Package Contents
• FLEXIDOME Panoramic 5100i IR
• 1 x Camera Base
• 1 x Camera dome cover
• 1 x TR20 Allen key for camera installation
• 1 x 8-pin Audio and I/O connector
• 1 x 2-pin power connector
• and more below
• , 1 x Mount plate, 1 x Quick installation guide, 1 x RJ-45 punch-through aid, 1 x Safety Information, 2 x M20 rubber grommets (attached to the camera), 3 x Installer UX Labels
