StarTech 10G2A1C25EPD-USB-HUB 3-Port USB-C 2.5Gb Ethernet USB-A 100W PDel HUB

Name: StarTech 10G2A1C25EPD-USB-HUB 3-Port USB-C 2.5Gb Ethernet USB-A 100W PDel HUB
Brand: Startech
SKU: INGaSTT JL9943 - 10G2A1C25EPD-USB-HUB
Price: 79.08 USD
Availability: InStock

$79.08 USD

Shipping calculated at checkout.

In stock: 2

Description

3-Port USB-C Hub with 2.5 Gbps Ethernet and 100W Power Delivery Pass-Through Port, USB 3.2 10Gbps, 2x USB-A/1x USB-C, Portable USB Type-C Adapter Hub

Enable 2.5G ethernet, 100W PD pass-through, and add three USB 3.2 10Gbps ports, using this portable adapter

Product ID: 10G2A1C25EPD-USB-HUB

Warranty Information

Warranty

2 Years

Connector(s)

External Ports

2 - USB 3.2 Type-A (9 pin, Gen 2, 10Gbps)

1 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)

1 - RJ-45

1 - USB Type-C (24 pin) USB Power Delivery Only

Host Connectors

1 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)

Environmental

Operating Temperature

0°C to 40°C (32°F to 104°F)

Storage Temperature

-10°C to 70°C (14°F to 158°F)

Humidity

10% to 85% RH

Hardware

USB-C Device Port(s)

Yes

USB-C Host Connection

Yes

Fast-Charge Port(s)

Interface

USB 3.2 Gen 2 - 10 Gbit/s

Bus Type

USB 3.2 Gen 2 10Gbps

Industry Standards

USB 3.2 Gen 2 - Backward compatible with USB 3.2 Gen 1, USB 2.0, and 1.1

USB Power Delivery 3.0

Wake on USB

IEEE 802.3bz (2.5GBASE-T/NBASE-T)

Chipset ID

VIA - VL103

VIA - VL822

Realtek - RTL8156B

Indicators

LED Indicators

1 - Network Link LED - Green

1 - Network Activity LED - Amber

Packaging Information

Package Height

1.2 in [3.0 cm]

Package Length

6.7 in [17.0 cm]

Shipping (Package) Weight

4.6 oz [129.0 g]

Package Width

5.6 in [14.2 cm]

Performance

Total USB Power Output

4.5W (5V/0.9A)

Wake On Lan

Yes

Maximum Data Transfer Rate

10Gbps (USB 3.2 Gen 2)

Type and Rate

USB 3.2 Gen 2 - 10 Gbit/s

UASP Support

Yes

Compatible Networks

2.5G/1G/100Mbps/10Mbps

Auto MDIX

Yes

PXE

Full Duplex Support

Yes

Jumbo Frame Support

9K max.

General Specifications

Maximum Laptop Charging: 85W

MTBF

286,501.33 Hours

Physical Characteristics

Color

Space Gray

Form Factor

Compact

Product Height

0.6 in [1.5 cm]

Product Length

1.3 in [3.4 cm]

Weight of Product

2.4 oz [68.0 g]

Product Width

6.4 in [16.3 cm]

Material

Plastic

Cable Length

12.0 in [30.5 cm]

Software

OS Compatibility

OS Independent; No additional drivers or software required

Special Notes / Requirements

Note

Not all USB-C ports support the full functionality of the USB Type-C standard. Ensure the host USB-C port supports USB Power Delivery.

Power will not pass through to the adapter when connected to a host USB-C port that lacks USB PD functionality.

USB 3.2 Gen 2 10Gbps is also known as USB 3.1 Gen 2 10Gbps

System and Cable Requirements

A host laptop with an available USB-C port (to ensure full adapter functionality, the host USB-C port must support USB Power Delivery).

Optional: USB-C power adapter (for example, your laptop's USB-C based power adapter).

What's in the Box

Included in Package

1 - USB-C Hub

1 - Quick-Start Guide
