Warranty

2 Years

Connector Type(s)

1 - USB 3.2 USB Type C (10 pin, Gen 2, 10 Gbps)

1 - USB 3.2 USB Type C (10 pin, Gen 2, 10 Gbps)

2 - USB 3.2 Type-A (9 pin, Gen 2, 10Gbps)

1 - RJ-45

Humidity

0% to 95% (non-condensing) at 25°C

Operating Temperature

0 to 50°C

Storage Temperature

-20 to 70°C

USB-C Device Port(s)

Yes

USB-C Host Connection

Yes

Ports

3

Interface

USB 3.2 Gen 2

Bus Type

USB 3.2 Gen 2 10Gbps

USB Pass-Through

Yes

Industry Standards

USB 3.2 Gen 2 - Backwards compatible with USB 3.0, 2.0, and 1.1

Chipset ID

Realtek - RTL5423
Realtek - RTL8153B

LED Indicators

1 - Green - Power and Link Indicator

Package Height

2.1 in [5.4 cm]

Package Length

8.5 in [21.6 cm]

Shipping (Package) Weight

1.0 lb [0.5 kg]

Package Width

6.0 in [15.2 cm]

Package Quantity

1

Wake On Lan

Yes

Maximum Data Transfer Rate

10 Gbps (USB 3.2 Gen 2)

Type and Rate

USB 3.2 Gen 2 - 10 Gbit/s

UASP Support

Yes

Supported Charging Modes

Charging Downstream Port (CDP)

Dedicated Charging Port (DCP)

Supported Charging Outputs

BC 1.2 (1.5A)

Apple 1A

Apple 2.4A

Port Multiplier

Yes

Compatible Networks

10/100/1000 Mbps

Auto MDIX

Yes

Full Duplex Support

Yes

Color

Black & Space Gray

Form Factor

Desktop

Product Height

1.0 in [2.5 cm]

Product Length

3.9 in [10.0 cm]

Weight of Product

3.1 oz [87.0 g]

Product Width

2.4 in [6.0 cm]

Material

Aluminum and Plastic

Cable Length

3.3 ft [1 m]

Power Source

AC Adapter Included

Input Voltage

100 - 240 AC

Input Current

0.8A

Output Voltage

12V DC

Output Current

2A

Center Tip Polarity

Positive

Plug Type

M

Power Consumption (In Watts)

24W

OS Compatibility

Windows® 11 (32/64 bit)
Windows® 11 ARM
Windows® 10 (32/64 bit)
Windows® 10 ARM
Windows® 8.1 (32/64bit)
Windows® 7 (32/64bit)
Windows® Server 2008 R2
Windows® Server 2012(32/64bit)
Windows® Server 2016
Windows® Server 2019
Windows® Server 2022
macOS 10.10-10.15, 11.0, 12.0, 13.0, 14.0
Linux Kernel 4.x LTS and up
Ubuntu 14.x LTS - 19.x LTS
iPadOS 13.1 and up Chrome OS 61.x and up
Android OS 8.x and up

Included in Package

1 - USB-C Hub

1 - Universal Power Adapter

4 - Power Adapter Clips (NA/JP, UK, EU, ANZ)

1 - 3.3 ft [1 m] USB-C Host Cable
